Запчасти Case IH PATRIOT NT (02-005) - AIR CONDITIONER Cab Exterior

1

BN98106

EVAPORATOR

1шт.

2

BN98191

COIL

Condenser

1шт.

3

BN98192

RECEIVER-DRYER

1шт.

4

BN68994

COMPRESSOR

1шт.

5

BN69427

BELT

1шт.

6

BN68682

MOUNTING PLATE

Lower Bracket

1шт.

7

BN68679

Upper Bracket

1шт.

8

BN98637

HOSE

13/32"

1шт.

9

BN98639

HOSE

5/16"

1шт.

10

BN98632

HOSE

1/2" X 265" (Low Pressure)

1шт.

11

BN98631

HOSE

5/16" X 265" (High Pressure)

1шт.

11a

BN67045

BLOWER

1шт.

Includes Refs. 12, 13, 14, & 15

1шт.

12

BN67044

HOUSING

Blower

1шт.

13

BN98564

MOTOR

12V 5/16 Double Shaft

1шт.

14

BN98722

FAN

2шт.

15

BN98565

RETAINER

2шт.

16

BN25982

AC Pulley

1шт.

Not Shown

1шт.

BN98808

FILTER

A/C Recirculation Filter, Not Shown

2шт.
