Запчасти Case IH PATRIOT 150 (03-002) - BATTERY & STEERING ARM (01) - ENGINE

1

BN63714

Boot-battery Red 2/0 Strt

1шт.

2

BN7020

ROD

5/16 dia. x 11.5

2шт.

3

BN29276

ANGLE

Battery Hold Down

1шт.

4

BN50057

LOCK NUT,Lock, 5/16"-18, Stainless Steel

2шт.

5

BN50141

WASHER

5/16, FW, G5

2шт.

6

BN50476

BOLT,5/16"-18 x 0.75", Stainless

2шт.

7

BN57234

BATTERY

12V, 950 CCA post

1шт.

8

BN67535

(-)

1шт.

9

BN24627

(+)

1шт.

10

BN66124

COVER

Assembly - Battery

1шт.

10a

BN29977

PLATFORM

Safety Walk - Flextread, 6" x 16"

1шт.

Service Parts For Ref. 10

1шт.

10b

BN67240

SEAL

Clip On

1шт.

Service Parts For Ref. 10

1шт.

11

BN21401

ELBOW,90 Degree 3/8" NPT x 7/16"-20 JIC

2шт.

12

BN65463

WASHER

Machine Bushing - 18 GA

2шт.

13

BN65464

WASHER

Machine Bushing - 14 GA

2шт.

14

BN65465

WASHER

Machine Bushing - 10 GA

2шт.

15

NSS

NOT SOLD SEPARAT

HYD. Cylinder Steering Patriot

1шт.

See Fig. 07-010

1шт.

16

BN10465

NIPPLE, LUBE,1/4"-28 st

NIPPLE

1шт.

17

BN25516

PIN

pivot - 1.03" x 12.5"

1шт.

18

BN50072

NUT

Hex, 1/2"-13, G5, PL

2шт.

19

BN50131

LOCK NUT

3/8-16, CTR, PL

2шт.

20

BN50269

BOLT

3/8-16 X 2.25, HH, 5, PL

2шт.

21

BN50894

BOLT

1/2"-13 x 2.5, HH, 5

2шт.

22

BN63711

FLANGED BEARING,25.4mm ID x 28.57mm OD x 31.75mm L

Flange - Plastic 1"

2шт.

23

BN63772

ARM

Steering

1шт.

8" FRM

1шт.

24

BN63780

PIN

1.03 dia. CRS x 10

1шт.

25

BN63790

BUSHING

1шт.
