Запчасти Case IH SRX160 (E.10.C[13]) - SUSPENDED BOOM - WINDSCREEN LAYOUT E - Body and Structure
![Схема запчастей Case IH SRX160 - (E.10.C[13]) - SUSPENDED BOOM - WINDSCREEN LAYOUT E - Body and Structure](https://partsell.ru/storage/images/caseih/1196779.png)
№
Артикул
Название
Примечание
Количество
0
87501991
PANEL
front lf 50" windscreen
1шт.
0
87501992
PANEL
rear lr 50" windscreen
1шт.
0
87501993
PANEL
front rf 50" windscreen
1шт.
0
87501994
PANEL
rear rr 50" windscreen
1шт.
0
87501995
PANEL
front lf 47" windscreen
1шт.
0
87501996
PANEL
rear lr 47" windscreen
1шт.
0
87501997
PANEL
front rf 47" windscreen
1шт.
0
87501998
PANEL
rear rr 47" windscreen
1шт.
0
NS
NOT SERVICED
PANEL assembly ws 67" front lt
1шт.
0
NS
NOT SERVICED
PANEL assembly ws 67" front rt
1шт.
0
NS
NOT SERVICED
PANEL assembly ws 64" rear
1шт.
0
NS
NOT SERVICED
PANEL windscreen assembly, front left - 57"
1шт.
0
NS
NOT SERVICED
PANEL windscreen assembly, rear left - 57"
1шт.
0
NS
NOT SERVICED
PANEL windscreen assembly, front right - 57"
1шт.
0
NS
NOT SERVICED
PANEL windscreen assembly, rear right - 57"
1шт.
Выбрано товаров: 15
