Запчасти Case IH SRX160 (L.20.B[04]) - PLUMBING - SUSPENDED BOOM - DETAILS L - Field Processing

1

80681

LOCK WASHER,5/16"

4шт.

2

9635082

NUT,5/16" - 18, Gr 5

4шт.

3

80664

WASHER,0.38" ID x 0.88" OD x 0.08" Thk

2шт.

4

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

2шт.

5

419990A1

U-BOLT

us 5/16" x 4 1/8" w x 4 3/4" d 3/4" thread

1шт.

6

87562259

FITTING,1" Male Thread x 1" 90 Degree Hose Barb

fitting, poly 90º 1" mpt 1" hb

2шт.

7

8610

REDUCER FITTING

poly bushing 1"mpt x 1/4"fpt

2шт.

8

87562261

NIPPLE,1-1/2" x 1" Poly Reducing Nipple

poly nipple 1 1/2" mp 1" mp

1шт.

9

22238

FITTING

poly straight adapter 2 flng x 1 1/2" fpt

1шт.

10

BN303204

GASKET,1-1/2" EPDM Gasket

2" Flange, EPDM

3шт.

11

87500051

VALVE

ball elec flng tee comp

2шт.

Refer to L.20.A [31]

1шт.

12

400502A1

CLAMP,80.96mm ID

2" flange banjo #fc200

3шт.

13

405783A1

FITTING,2" Flange x 1-1/4" 90 Degree Hose Barb Elbow

poly 90º 2" flange x 1 1/4" hose barb

1шт.

14

87501983

FRAME

ball valve mount, Years: -01-JAN-07

1шт.

14

87620878

PLATE

ball valve mount, Start Year: 01-FEB-07

1шт.
