Запчасти Case IH SPX4410 (01-004[04]) - INTERIOR TRIM, DELUXE Cab Interior

1

410864A1

INSULATOR

REAR FLOOR

1шт.

2

283094A1

FILTER

CAB RECIRCULATION

1шт.

3

60-7021T1

FOAM

CABLE CLAMP

4шт.

4

291835A4

BRACKET

CLAMP, CABLE

1шт.

5

86624182

WASHER,6.6mm ID x 18mm OD x 1.6mm Thk

4шт.

6

360827A2

PAD, RUBBER

COVER, LEFT A POST INTERIOR

1шт.

7

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

8шт.

8

259461A1

FOAM

REAR ROPS

3шт.

9

414926A1

BEZEL

RH A POST

1шт.

10

303158A5

BRACKET

BRACKET

1шт.

11

87016541

SELF-TAP SCREW,Phillips Drive, Pan HD, #10 - 16 x 1"

2шт.

12

628-6020

BOLT,Hex, M6 x 20mm, Cl 10.9, Full Thd

6шт.

13

308955A2

BRACKET

REAR SUPPORT

1шт.

14

87608402

FLOOR MAT

BUDDY STORAGE

1шт.

15

291836A3

BRACKET

CLAMP, CABLE

1шт.

16

308579A1

BRACKET

ANGLE, CABLE ACCESS

2шт.

17

86500688

NUT,Hex, M6 x 1.0, Cl 10.9

12шт.

18

86639271

BOLT,Hvy Hex, M8 x 30mm, Cl 10.9, Full Thd

5шт.

19

87561589

FLOOR MAT

1шт.

20

358334A4

COVER

RH A -POST ROPS

1шт.

21

360826A3

PAD, RUBBER

LEFT C POST INTERIOR

1шт.

22

377385A3

COVER

RH C-POST ROPS

1шт.

23

380756A2

COVER

ELECTRONICS

1шт.

24

358327A4

CONSOLE

REAR

1шт.

25

1961435C1

LATCH

CAB SKIRT SPRING

1шт.

26

86637656

RIVET,Pop, 1/8" x .337"

6шт.

27

1977929C1

STUD,M5 x 0.8

BALL

1шт.

28

119308A2

TRAY

storage

1шт.

29

349366A2

FOAM

TAPE

1шт.

30

355371A2

TAPE

foam

1шт.

31

356717A1

TAPE

foam

2шт.

32

114549A1

COAT HOOK

1шт.

33

765-17316

SELF-TAP SCREW,Oval Hd, M4.2 x 16

2шт.

34

369937A1

NET

CARGO

1шт.

35

369929A1

FASTENER

CHRISTMAS TREE

5шт.

36

371554A1

BRACKET

DOOR

1шт.

37

376553A1

FASTENER

CHRISTMAS TREE

3шт.

38

177269A1

SPRING NUT,M4.2

2шт.

39

80043233

SCREW

Hex, M8 x 20, 10.9

4шт.

40

384758A1

FOAM INSULATION

BARRIER, FRONT CONSOLE

1шт.

41

384786A2

FOAM

FRONT CONSOLE

1шт.

42

381027A1

FOAM INSULATION

ACOUSTICAL

1шт.

43

376597A2

DECAL

hole

5шт.

44

394772A1

PAD SET

FLOOR PROTECTION

1шт.

45

86639049

PLUG

Cap 1/2" Hole, Black Poly

2шт.

46

345-103

LOCTITE

593

1шт.

47

325228A1

DECAL

SERIAL NUMBER

1шт.

48

307026A1

SHIELD

CABLE ACCESS

1шт.

49

9804278

FLANGE NUT,M10 x 1.5, Cl 8

1шт.

50

86639232

NUT,Weld, M10

1шт.

51

561-707

HEX SOC SCREW,M10 x 34.4, 12 x 30mm shldr, Cl 12.9

1шт.

87409368

CAB FILTER

RECIRCULATION

1шт.

Associated Part Of Interior Trim Group

1шт.

87408613

INSULATION

RECIRCULATION

1шт.

Associated Part Of Interior Trim Group

1шт.
