2
BN301998
DOWEL
Hollow
1шт.
4
BN302052
WASHER,20.32mm ID x 139.7mm OD
1шт.
6
BN312604
SPACER
Shim - Axle
1шт.
12
BN320759
STOP
tab, axle adjust
1шт.
13
87268923
BAR
Axle Slide
1шт.
16
87721678
AXLE
Rear
1шт.
17
87268927
SLIDE
axle adjuster, RR
1шт.
18
342939A1
SLEEVE
dowel, hollow
2шт.
22
627-20035
BOLT,Hex, M20 x 2.5 x 35mm, Cl 10.9, Full Thd
M20-2.5 X 35, HH, 10.9
1шт.
23
86624002
BOLT,Hex, M20 x 40mm, Cl 8.8
1шт.
24
627-20055
BOLT,Hex, M20 x 2.5 x 55mm, Cl 10.9, Full Thd
1шт.
28
264031
NUT,M20 x 2.5, Cl 10
2шт.
31
87268646
BOLT,M20 x 2.5 x 100mm, Cl 12.9
M20-2.5 X 100, 12PT, 12.9, DRL
2шт.
32
892-11020
LOCK WASHER,M20
1шт.
34
87529307
WASHER,22mm ID x 37mm OD x 4mm Thk
22 x 37 x 4 mm, HDN, DOR
6шт.
36
NS
NOT SERVICED
Hose Pivot Group, RR
1шт.
See Fig. 04-008
1шт.
38
9846950
BOLT,Hex, M20 x 2.5 x 90mm, Cl 10.9
1шт.
