Запчасти Case IH SPX4410 (02-007) - WINDOW GROUP Cab Exterior

1

389175A3

WINDOW ASSY

1шт.

2

87423532

PIN

RH Door Catch

1шт.

3

86050303

NUT

M8 x 1.25, Flg, Cl 8

1шт.

4

87429877

BUSHING,12.01mm ID x 15.06mm OD x 8mm L

Flanged

2шт.

5

87423389

DAMPER

Gas Cylinder

1шт.

6

130003

COTTER PIN,3mm OD x 30mm OAL

1шт.

7

9849996

CLIP

Retainer Ball Stud

2шт.

87418389

LATCH ASSY.

RH Door

1шт.

Service Parts For Rev. 7

1шт.

87420877

BRACKET

Latch Mounting

1шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

87422906

BUSHING,6.5mm ID x 19mm OD x 6.9mm L

M6

1шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

87423414

WASHER

Nylon

2шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

87423716

CAP

Vinyl

1шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

1шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

3шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

832-10406

NUT,M6 x 1, Cl 8

1шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

86639037

BOLT,Hex, M6 x 16mm, Cl 10.9, Full Thd

2шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.

9804276

FLANGE NUT,Hex, M6 x 1, Cl 8

2шт.

Associated Part Of Latch, RH Door, P/N 87418389

1шт.
