Запчасти Case IH SPX4410 (06-024) - LADDER, HYDRAULIC LIFT "SERIAL # 7096 AND LATER" Hydraulic Plumbing

1

BN302547

90 ELBOW

9/16-18 x 7/16-20, ZND

1шт.

2

87266443

HYDRAULIC CYLINDER,12.7mm Rod, 152.4mm Stroke

1 x 6 x 0.5, Complete

1шт.

See Fig. 07-006

1шт.

3

BN325314

HOSE ASSY.

4 X 98"

1шт.

4

86624079

HEADED PIN,3/8" x 1 1/4", G2

1шт.

5

BN50075

NUT

1/2-20 Hex SS

1шт.

6

BN305412

O-RING

For -6 FFOR

1шт.

7

BN313268

ORIFICE

.042 -6 Disk

1шт.

8

BN71006

COTTER PIN

1/8", #11

2шт.

9

439-1824

HEADED PIN,1/2" x 1 1/2", G2

1шт.

10

BN21982

CLEVIS,1/2" - 20

1" Diameter CRS x 1.87

1шт.

11

9827902

CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type

3шт.

12

87344227

SERRATED NUT

Serrated, M8 SPL DOR

3шт.

14

87267314

BREATHER

Sintered -4 SAE

1шт.
