(291) - FRONT HINGE ASSEMBLY

Запчасти Case IH SPX4260 (291) - FRONT HINGE ASSEMBLY (78) - SPRAYING

Схема запчастей Case IH SPX4260 - (291) - FRONT HINGE ASSEMBLY (78) - SPRAYING
2
5
1
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

811-8030

CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 30mm, Cl 8.8

4шт.

Part available only through Case's North American Parts Organization (NAPO).

1шт.

2

BN310764

MOUNTING PARTS

pan, front

1шт.

3

BN311771

MOUNTING PLATE

Front

1шт.

4

86528579

NUT,M8 x 1.25

4шт.

5

BN300506

WASHER

M8, Stainless Steel

4шт.
