Запчасти Case IH SPX4260 (04-031) - HOOD GROUP, LOWER Suspension & Frame

1

232449A2

HEADLIGHT,Halogen/Incandescent, 12V, Clear

left, RH dip roe

1шт.

2

232448A2

HEADLIGHT,Halogen/Incandescent, 12V, Clear

right, RH dip roe

1шт.

3

232455A2

WORK LAMP,HID, 12V, 35W, Clear

center, HID - Includes Bulb (NSS due to cost)

1шт.

4

281-54712

SCREW,Hex Wshr Hd, 1/4" - 20 x 3/4"

4шт.

5

BN316956

PIN

Light Adjust

2шт.

6

342567A1

BRACKET

Headlights

1шт.

7

BN316970

SUPPORT

Light Mount

1шт.

8

343699A1

HOOD

Lower, Complete

1шт.

9

322332A1

BALLAST

light, center HID

1шт.

10

333643A1

GASKET

foam HID ballast

1шт.

11

333644A1

GASKET

foam HID ballast hold down

1шт.

12

333645A1

CLAMP

HID ballast hold down

1шт.

13

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

2шт.

14

11106231

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9

8шт.

15

353308

NUT,M6 x 1.0, Cl 8

17шт.

16

86528579

NUT,M8 x 1.25

2шт.

17

100037

LOCK NUT,M10 x 1.5, Cl 8

8шт.

18

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

23шт.

19

86624184

WASHER,9mm ID x 16mm OD x 1.6mm Thk

1шт.

20

86639325

WASHER,10.8mm ID x 24.5mm OD x 3mm Thk

16шт.

21

151-509

RIVET,Pop, 3/16" x .325"

6шт.

22

259713A1

CLIP

Light Mounting

6шт.

23

120100

BOLT,M6 x 20mm, Cl 8.8

9шт.

24

342538A1

FOAM

Fuel Tank Hood

1шт.
