Запчасти Case IH SPX4260 (04-003) - BATTERY GROUP W/CABLES Suspension & Frame

Схема запчастей Case IH SPX4260 - (04-003) - BATTERY GROUP W/CABLES Suspension & Frame

Артикул

Название

Примечание

Количество

0

BN306467

ELECTRICAL WIRE

WIRE Assembly, 2/0 Black 12

1шт.

0

BN306555

TERMINAL CONNECTOR

Jump, Battery, Pos, W/Cap

1шт.

0

BN306556

TERMINAL CONNECTOR

Jump, Battery, Neg, W/Cap

1шт.

0

BN320013

CABLE

Positive (Battery To Battery)

1шт.

0

BN320014

CABLE

Negative (Battery To Battery)

1шт.

0

BN320843

CABLE

1/0 Red 86 (Battery To Jumper)

1шт.

0

BN320844

CABLE

1/0 Black 86 (Battery To Jumper)

1шт.

0

BN322077

POS BATTERY CABLE

2/0 Red 103 (Battery To Starter)

1шт.

0

BN322079

CABLE

2/0 Black 113 (Battery To Engine)

1шт.

0

BN322080

CABLE

1/0 Black 123 (Battery To Cab)

1шт.

0

342112A1

CABLE

1/0 Red (Fuse To Cab)

1шт.

0

342113A1

CABLE

1/0 Black (Cab To Frame)

1шт.

0

BN50062

LOCK NUT,3/8"-16, Stainless Steel

4шт.

0

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

1шт.

0

9706687

BOLT,M12 x 1.75 x 30mm, Cl 8.8

1шт.

0

100037

LOCK NUT,M10 x 1.5, Cl 8

1шт.

0

91734C1

WET BATTERY

12V, 950CCA, Stud

2шт.

Выбрано товаров: 17
