Запчасти Case IH SPX3320 (01-030) - M49 RH CONSOLE GROUP - END YEAR 01/2009 Cab Interior

1

87270586

RH CONSOLE SUBASSY, M49

1шт.

See Fig. 01-031

1шт.

2

NS

NOT SERVICED

Lever, Prop Control Assembly

1шт.

See Fig. 01-040

1шт.

3

87271786

RH CONSOLE THROTTLE GRPL

1шт.

See Fig. 01-038

1шт.

4

87270766

RH CONSOLE MOUNT ASSY

1шт.

See Fig. 01-034

1шт.

5

87271591

RH CONSOLE, ELEC, 786/787

1шт.

See Fig. 01-033

1шт.
