(10-002[02]) - APPEARANCE GROUP, NON SPX, BEGINNING 6/01/07

Запчасти Case IH SPX3320 (10-002[02]) - APPEARANCE GROUP, NON SPX, BEGINNING 6/01/07 (13) - DECALS

Схема запчастей Case IH SPX3320 - (10-002[02]) - APPEARANCE GROUP, NON SPX, BEGINNING 6/01/07 (13) - DECALS
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

1968108C2

TRIM

Trim, Hood Sight

1шт.

2

311863A1

REFLECTOR

Reflective Red

4шт.

3

311864A1

REFLECTOR

Reflective Amber

10шт.

4

311865A1

REFLECTOR

Fluorescent Orange

2шт.

5

87716230

EMBLEM

Case IH Logo

1шт.

6

87636743

DECAL

3320, RH Front Hood

1шт.

7

87636744

DECAL

3320, LH Front Hood

1шт.

8

87636745

DECAL

3320, RH Rear Hood

1шт.

9

87636746

DECAL

3320, LH Rear Hood

1шт.

10

86625060

PUSH-ON NUT,Self, Threading, 1/4"

2шт.

11

87558404

DECAL

CASE IH, Rear, Raised of Front Hood

2шт.
