Запчасти Case IH SPX3320 (10-001[01]) - APPLICATION GROUP (13) - DECALS

1

87653647

DECAL

Case Application Eq

1шт.

2

343736A1

DECAL

Station Function 778D

1шт.

2a

84165752

DECAL

STA function - Russian

1шт.

3

343189A1

DECAL

Foamer Function 778D

1шт.

3a

84165753

DECAL

foamer function - Russian

1шт.

4

344405A1

DECAL

Emergency Stop

1шт.

5

BN323729

DECAL

Hand Wash

1шт.

6

87271664

DECAL

Rinse, Chemical Inductor

1шт.

7

87271661

DECAL

Rinse, Chemical Inductor

1шт.

7a

84165755

DECAL

rinse, chemical inductor - Russian

1шт.

7b

84165748

DECAL

rinse, chemical inductor - Russian

1шт.

8

87271662

DECAL

TANK SUMP

1шт.

8a

84165757

DECAL

tank sump - Russian

1шт.

9

343184A1

DECAL

Product Tank Fill 778D

1шт.

9a

84165759

DECAL

prod tank fill - Russian

1шт.

10

87271665

DECAL

Foam Tank, Fill

1шт.

10a

84165761

DECAL

foam, fill - Russian

1шт.

11

87271663

DECAL

Rinse Tank

1шт.

11a

84165765

DECAL

rinse tank - Russian

1шт.

12

87580661

SIGHTGLASS

FRONT

1шт.

13

87580663

DECAL

GAUGE, SIDE

1шт.

14

87580665

SIGHTGLASS

UPPER

1шт.

15

87593257

SIGHTGLASS

REAR

1шт.

16

84166107

DECAL

circuit pressure - Russian

1шт.

Not Shown

1шт.

17

84166102

DECAL

clean water only- Russian

1шт.

Not Shown

1шт.

18

84165770

DECAL

chemical inductor - Russian

1шт.

Not Shown

1шт.
