Запчасти Case IH SPX3320 (11-009) - NOZZLE, FENCE ROW, 90’, LO-FLOW Options

1

87265461

PLUG

2" Flange X 1/4" FP

2шт.

2

BN1420036

NIPPLE

1/4" Close SS

2шт.

3

343778A1

SOLENOID

valve, 1/4" NPT

2шт.

4

BN2399403

ADAPTER

1/4" MPT x 3/8" OD Tube, Push Lock Fitting

4шт.

5

86986105

CLAMP

Plate, Nozzle

2шт.

6

BN313361

NIPPLE,1/4" NPT x 6mm SS

NIPPLE

2шт.

7

BN73015

COUPLING

1/4" NPT SS Full

2шт.

8

BN313256

NOZZLE INJECTION

W/SWIVEL

2шт.

9

BN313255

NOZZLE INJECTION

W/CHECK VALVE

2шт.

9a

BN74619

CAP

Service Part for Ref 9

1шт.

11

87269955

TUBE,0.375" DIA x 122" L

3/8 X 122, SYN BLK

2шт.

9b

BN69558

PLUG

Service Part for Ref 9

1шт.

10

NS

NOT SERVICED

ELECT GRP, FENCE ROW SEE FIG 12-055

1шт.
