(09-058) - BOOM PLUMBING GROUP, 5-6 SECTION 100’

Запчасти Case IH SPX3320 (09-058) - BOOM PLUMBING GROUP, 5-6 SECTION 100’ Liquid Plumbing

Схема запчастей Case IH SPX3320 - (09-058) - BOOM PLUMBING GROUP, 5-6 SECTION 100’ Liquid Plumbing
6
2
5
2
5
3
5
4
1
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

BN313202

ELBOW

1-1/4" NPT, 90°, Poly

1шт.

2

BN73657

FITTING,1-1/4" Male NPT x 1" Hose Barb, Poly

1-1/4" NPT x 1" Hose Barb, Poly

2шт.

3

BN73662

TEE

1-1/4", Poly

1шт.

4

87743696

FITTING

1-1/4" NPT X 1-1/4" Hose Barb, Poly

1шт.

5

BN310447

HOSE CLAMP

#20, Stainless Steel

3шт.

6

BN53479

HOSE,1.00" ID BULK

Bulk, Cut to 120"

1шт.

7

342228A1

HOSE,31.8mm ID x 30480mm L

Bulk, Cut to 108"

1шт.
