(09-049) - SPRAYBAR, 100’ OUTER, 20’ OFF CL

Запчасти Case IH SPX3320 (09-049) - SPRAYBAR, 100’ OUTER, 20’ OFF CL Liquid Plumbing

Схема запчастей Case IH SPX3320 - (09-049) - SPRAYBAR, 100’ OUTER, 20’ OFF CL Liquid Plumbing
10
5
1
10
6
2
6
3
5
9
3
6
4
9
7
4
8
6
2
7
5
9
5
3
7
2
1
3
4
4
8
2
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87562807

BRACKET, SUPPORTING

Mount, Spraybar

2шт.

2

BN319919

U-BOLT

Sq. Bend 2.06 ID x 3/8

4шт.

3

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

8шт.

4

BN67054

CLAMP

1.315" OD

4шт.

5

BN309483

PLATE

Clamp Top, Single Clamp

4шт.

6

BN67050

BOLT,1/4"-20 X 3.00", Stainless Steel

8шт.

7

BN55359

LOCK NUT,1/4"-20, SS

8шт.

8

87266668

PIPE,105" Long, 6 Holes, 20" Nozzle Spacing

Spraybar, 6 Nozzles, 20" Nozzle Spacing, Stainless Steel, 105" Long

2шт.

9

BN73606

CAP

1" NPT, Poly Pipe

4шт.

10

87562807

BRACKET, SUPPORTING

Mount, Spraybar

2шт.
