Запчасти Case IH SPX3310 (06-043) - FRONT LADDER HYDRAULIC GROUP - SERIAL #7440 AND LATER Hydraulic Plumbing

1

BN302547

90 ELBOW

9/16-18 x 7/16-20, ZND

1шт.

2

87266443

HYDRAULIC CYLINDER,12.7mm Rod, 152.4mm Stroke

1 x 6 x 0.5, Complete

1шт.

See Fig. 07-006

1шт.

3

87272042

HOSE

4 X 97"

1шт.

4

BN305411

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

FOR 4FFOR

1шт.

5

BN319639

ORIFICE

M4MOR (.042)

1шт.

6

BN50075

NUT

1/2-20 HEX SS

1шт.

7

86624079

HEADED PIN,3/8" x 1 1/4", G2

1шт.

8

80756

COTTER PIN,1/8" x 3/4"

1шт.

9

439-1824

HEADED PIN,1/2" x 1 1/2", G2

1шт.

10

87267314

BREATHER

Sintered -4 SAE

1шт.

11

BN21982

CLEVIS,1/2" - 20

1" Diameter CRS x 1.87

1шт.

12

86625036

CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type

1шт.

13

86528579

NUT,M8 x 1.25

1шт.

14

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

1шт.

15

86624184

WASHER,9mm ID x 16mm OD x 1.6mm Thk

1шт.

16

432-1216

COTTER PIN,3/16" x 1"

1шт.
