(06-028) - VALVE BANK MOUNTING GROUP - SERIAL #20002 AND LATER

Запчасти Case IH SPX3310 (06-028) - VALVE BANK MOUNTING GROUP - SERIAL #20002 AND LATER Hydraulic Plumbing

Схема запчастей Case IH SPX3310 - (06-028) - VALVE BANK MOUNTING GROUP - SERIAL #20002 AND LATER Hydraulic Plumbing
5
6
2
3
4
2
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87272239

PLATE

MTG-VALV BANK

1шт.

2

BN50232

BOLT,5/16"-18 x 1.00", Stainless Steel

8шт.

3

87343959

NUT,5/16" - 18, GR B, DOR

4шт.

4

87272733

SPACER

VALVE MOUNT

2шт.

5

87398981

COVER

VALVE BANK BOX, Start Serial: 20656

1шт.
