Запчасти Case IH SPX3310 (08-011) - MOUNT GROUP (09) - BOOMS

1

87269351

SUPPORT

Mount, Rear Tank

4шт.

2

86986975

SPACER

10" U-Bolt

6шт.

3

87268745

BRACKET, SUPPORTING

DRIVE HOSES, L.H.

1шт.

4

412066

NUT,M16 x 2.0, Cl 8

16шт.

5

343924A1

U-BOLT

U, M16-2, 150 x 256

8шт.

6

87268744

BRACKET, SUPPORTING

DRIVE HOSES, R.H.

1шт.
