Запчасти Case IH SPX3200B (017) - ENGINE GROUP (10) - ENGINE

Схема запчастей Case IH SPX3200B - (017) - ENGINE GROUP (10) - ENGINE
4
5
1
8
10
3
7
9
6
2

Артикул

Название

Примечание

Количество

1

NSS

NOT SOLD SEPARAT

ASSY., cable, throttle

1шт.

See Fig. 051

1шт.

ns

NSS

NOT SOLD SEPARAT

PKG, cleaner, air

1шт.

See Fig. 044

1шт.

ns

NSS

NOT SOLD SEPARAT

HDW., hydstat mtg. group

1шт.

See Fig. 050

1шт.

ns

BN314577

PACKING

radiator

1шт.

NSS

NOT SOLD SEPARAT

GROUP, shroud, mounting

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 053

1шт.

NSS

NOT SOLD SEPARAT

GROUP, radiator, mounting

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 054

1шт.

NSS

NOT SOLD SEPARAT

GROUP, radiator, components

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 055

1шт.

NSS

NOT SOLD SEPARAT

GROUP, cover, radiators

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 056

1шт.

NSS

NOT SOLD SEPARAT

GROUP, mount, grille and A/C

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 057

1шт.

NSS

NOT SOLD SEPARAT

GROUP, radiator, baffling

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 058

1шт.

ns

BN314579

HOOD

GROUP, engine, shield

1шт.

BN310739

SEAL

PKG., shield eng., lower hood

1шт.

» Indicates parts of an "assembly"

1шт.

BN310740

SHIELD

PKG., altern

1шт.

» Indicates parts of an "assembly"

1шт.

BN314935

FOAM

package, hood, engine

1шт.

» Indicates parts of an "assembly"

1шт.

ns

BN314581

PACKING

GROUP, exhaust

1шт.

NSS

NOT SOLD SEPARAT

ASSY., muffler

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 047

1шт.

NSS

NOT SOLD SEPARAT

GRP., shield, heat

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 046

1шт.

BN314582

PACKING

engine

1шт.

2

NSS

NOT SOLD SEPARAT

PKG., alternator

1шт.

See Fig. 043

1шт.

3

NSS

NOT SOLD SEPARAT

PKG., starter, with hdwe

1шт.

See Fig. 018

1шт.

4

NSS

NOT SOLD SEPARAT

COUPLR, flywhl, with hdwe

1шт.

See Fig. 019

1шт.

BN314934

ENGINE

CDC 5.9L - 200 HP ASY

1шт.

» Indicates parts of an "assembly"

1шт.

362559A1

ENGINE

CDC 200 HP, 6TA-590

1шт.

» Indicates parts of an "assembly"

1шт.

BN314986

TEMPERATURE SENDER

engine, service

1шт.

» Indicates parts of an "assembly"

1шт.

5

326347A1

TEMPERATURE SENDER

temperature 1/2-14 NPTF

1шт.

6

BN319998

SENDER UNIT

oil pressure

1шт.

NSS

NOT SOLD SEPARAT

GROUP, A/C

1шт.

See Fig. 010

1шт.

BN314933

HARNESS

group, engine, elec.

1шт.

NSS

NOT SOLD SEPARAT

ASSY., battery, pkg.

1шт.

See Fig. 049

1шт.

7

NSS

NOT SOLD SEPARAT

SOL. MNT., with SHIELD

1шт.

See Fig. 048

1шт.

8

BN313005

HARNESS

engine, CDC200

1шт.

BN314936

HOSE, BULK

HOSE, METERS system, delivery, fuel

1шт.

9

BN311452

FUEL HOSE,9.53 mm ID x 2997.20 mm, SAE 30R6, SAE 30R7

FUEL 3/8" x 118"

1шт.

10

BN311454

FUEL HOSE,7.94 mm ID x 2540.0 mm

FUEL 5/16" id x 100"

1шт.

NSS

NOT SOLD SEPARAT

FILTER, fuel, remote, pkg.

1шт.

» Indicates parts of an "assembly"

1шт.

See Fig. 059

1шт.

NSS

NOT SOLD SEPARAT

GROUP, mounts, engine

1шт.

See Fig. 045

1шт.

Выбрано товаров: 70
