Запчасти Case IH SPX3200 (02-008) - A/C PACKAGE (50) - CAB CLIMATE CONTROL

BN67796

TUBE

DRAIN, poly loom

3шт.

1

BN311013

HOUSING ASSY.

evaporator

1шт.

See Refs. 1 - 8 below

1шт.

2

BN67785

CONDENSER

Coil

1шт.

3

BN317005

GROUP, receiver, dryer

1шт.

See Refs. 1 - 7 on Fig. 02-010

1шт.

4

BN311014

PACKAGE

parts, louver & misc.

1шт.

See Refs. 3 - 14 on Fig. 02-010

1шт.

1

BN311015

EVAPORATOR

coil, heater

1шт.

2

BN69702

PRESSURE SWITCH

Lower, Housing assy

1шт.

3

BN69708

VALVE

Water, Inline, Housing assy

1шт.

4

BN311016

CABLE

assembly, push pull

1шт.

5

BN69872

VALVE, THERMAL EXPAN,Air Conditioing

Expansion, Housing assy

1шт.

6

BN69703

SWITCH

Cold Control, Housing Assy

1шт.

7

73107110

BLOWER SWITCH

3 Speed

1шт.

8

BN69704

BLOWER

12V, Housing assy

1шт.
