(04-024) - WALKWAY GROUP, CENTER SECTION

Запчасти Case IH SPX3200 (04-024) - WALKWAY GROUP, CENTER SECTION (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH SPX3200 - (04-024) - WALKWAY GROUP, CENTER SECTION (90) - PLATFORM, CAB, BODYWORK AND DECALS
4
2
5
1
3
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

280736

NUT,5/16"-18, GC

7шт.

2

86637953

WASHER,0.34" ID x 0.69" OD x 0.09" Thk

7шт.

3

87872

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

7шт.

4

BN319619

EXTENSION

WALKWAY, center section, L.H.

1шт.

5

BN319620

EXTENSION

WALKWAY, center section, R.H.

1шт.
