Запчасти Case IH SPX3200 (11-016) - CHEMICAL INDUCTOR-ELLIPTICAL (78) - SPRAYING

1

BN319931

TANK GRP., w/ linkage

1шт.

2

BN323022

VALVE ASSY, jug & tank (IND)

1шт.

3

BN322109

INDUCTOR TEE ASSY., w/MT

1шт.

4

BN317595

HOSE,1.50" ID x 65.00"

Kaniflex

1шт.

5

BN322958

FLEXIBLE HOSE,1.50" ID x 90.00"

Kanaflex

1шт.

6

BN322114

HOSE,1.50" ID x 16.00"

Kanaflex

1шт.

7

BN2293386

CLAMP

hose H28 SS

6шт.

8

BN322003

FITTING,2" Flange x 1" 90 Degree Hose Barb Elbow

2" Flange x 1" Hose Barb

1шт.

9

BN66857

HOSE

1" EPDM x 15.00"

1шт.

10

BN75978

HOSE CLAMP

SS, No. 12 adj., HS, .56-1.25

2шт.

11

BN75956

CLAMP

#10 SS

2шт.

12

BN50254

BOLT,3/8"-16 x 1", Stainless

7шт.

13

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

7шт.

14

BN50146

WASHER,3/8", Stainless

1шт.

15

BN52035

CLAMP

2" Dia., Vinyl Coated

1шт.

16

BN50476

BOLT,5/16"-18 x 0.75", Stainless

1шт.

17

BN55361

NUT,5/16"-18, Nylon, Stainless

1шт.

18

BN322903

MOUNTING PLATE

valve

1шт.

19

333088A1

DECAL

protective clothing

1шт.
