Запчасти Case IH SPX3200 (09-004) - LIQ. PLUMB, PRESS-750- SPHERICAL (78) - SPRAYING

1

NSS

NOT SOLD SEPARAT

PUMP & STRAINER ASSY.LIQ.

1шт.

See Fig. 09-029

1шт.

2

NSS

NOT SOLD SEPARAT

FITTING ASSY, PRESS-SPHER.

1шт.

See Fig. 09-014

1шт.

3

BN318772

HOSE,0.25" ID x 126.50"

EPDM

1шт.

4

BN76094

HOSE CLAMP

SS #M4

2шт.

5

BN73017

ELBOW

90 street 1/4" SS

1шт.

6

BN317167

HOSE,0.38" ID x 96.00"

EPDM

1шт.

7

BN75978

HOSE CLAMP

SS, No. 12 adj., HS, .56-1.25

4шт.

8

BN73562

FITTING,3/4" Male Thread x 3/4" 90 Degree Hose Barb

3/4" NPT x 3/4" Hose Barb, 90°

2шт.

9

406148A1

FITTING

bulkhead 3/4" dfpt c/w epdm gasket

2шт.

10

BN73649

NIPPLE,1" x 3/4" Poly Reducing Nipple

1" x 3/4" Poly

1шт.

11

29568

NOZZLE

Rinse 360 Degree

1шт.

12

BN53738

FLEXIBLE HOSE,0.75" ID x 18.50"

1шт.

13

BN73560

TEE

3/4" poly pipe

1шт.

14

BN73550

BUSHING

Reducer, 3/4" MPT x 1/4" FPT, Poly

1шт.

15

BN53734

ELBOW

90° 1/4" NPT x 9/16" JIC

1шт.

16

BN67392

HOSE

3/8" x 144" EPDM

1шт.

17

BN73565

NIPPLE,3/4" Male NPT x 3/4" Male NPT, Poly

3/4" Short Pipe, Poly

2шт.

18

BN73564

VALVE

3/4" Ball Poly 2 Way

1шт.

19

BN73566

ELBOW,3/4" Male NPT x 3/4" Female NPT, Poly

90, Street, 3/4" Poly

1шт.

20

BN304248

AGITATOR

Tank Mixing

1шт.

21

BN322957

HOSE, kanaflex, 1.5" x 11.5

1шт.

22

BN53811

CLAMP

2" ID, T-bolt

4шт.

23

413083A1

PIPE FITTING,1-1/2" Male Thread x 1-1/2" Hose Barb

Hose Barb, 1 1/2"

1шт.

24

NSS

NOT SOLD SEPARAT

VALVE & TEE ASSY., CHEM.

1шт.

See Fig. 09-027

1шт.

28

BN322011

HOSE, 1.5" x 88" EPDM

1шт.

29

BN310467

ELBOW

1-1/2" NPT x 1-1/2" NPT, Poly, 45º

1шт.

30

BN73733

FITTING

1 1/2" Bulkhead

1шт.

31

BN317593

HOSE,2.00" ID x 15.00"

EPDM

1шт.

32

BN2403358

CLAMP,50.8mm - 63.5mm

T-Bolt Band 2 1/2"

4шт.

33

BN317594

HOSE,2.00" ID x 96.00"

EPDM

1шт.

37

BN313773

CLAMP,2" Full Port

2" Flange

1шт.

38

BN313772

GASKET,2" Full Port, EPDM

2" Flange, EPDM

1шт.

39

BN319905

MOUNT, liquid pump

1шт.

40

BN50254

BOLT,3/8"-16 x 1", Stainless

4шт.

41

BN50146

WASHER,3/8", Stainless

8шт.

42

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

4шт.

46

BN53433

FITTING

HB, 1/4" NPT x 1/4" HS, STL

1шт.

48

BN303204

GASKET,1-1/2" EPDM Gasket

2" Flange, EPDM

1шт.

49

BN303199

CLAMP,2" Flange

2" Standard Flange

1шт.

50

434039A1

FITTING,2" Flange x 1-1/2" Hose Barb

2" Manifold x 1-1/2" Hose Barb, Poly

1шт.
