Запчасти Case IH SPX3200 (03-002) - ENGINE GROUP (10) - ENGINE

1

ASSY., throttle CBL

1шт.

See Fig. 03-072

1шт.

ns

PKG., air cleaner

1шт.

See Fig. 03-060

1шт.

ns

GROUP, HDW. hydstat. mtg.

1шт.

See Fig. 03-071

1шт.

ns

323030

FLEXIBLE HOSE

PKG., radiator

1шт.

GROUP, shroud mounting

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-074

1шт.

GROUP, radiator mounting

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-076

1шт.

GROUP, radiator components

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-078

1шт.

GROUP, radiator covers

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-080

1шт.

GRILLE, A\C mount group

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-083

1шт.

GROUP, radiator baffling

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-084

1шт.

ns

323031

HOSE

FLEXIBLE HOSE GROUP, exhaust

1шт.

MUFFLER ASSY.

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-067

1шт.

GROUP, heat shield

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-066

1шт.

ns

BN314582

PACKING

engine

1шт.

2

PKG., alternator

1шт.

See Fig. 03-059

1шт.

3

PKG., starter w/HDWE

1шт.

See Fig. 03-004

1шт.

4

COUPLER, flywheel, w/HDWE

1шт.

See Fig. 03-005

1шт.

BN314934

ENGINE

CDC, 5.9L-200HP ASSY.

1шт.

Indicates part of an assembly

1шт.

362559A2

ENGINE ASSEMBLY

ENGINE ASSY CDC (6TA-590) 200 Hp

1шт.

Indicates part of an assembly

1шт.

BN314986

TEMPERATURE SENDER

engine, service

1шт.

Indicates part of an assembly

1шт.

5

326347A1

TEMPERATURE SENDER

temperature 1/2-14 NPTF

1шт.

6

BN319998

SENDER UNIT

oil pressure

1шт.

331-327

OIL, 1 QT. DSL ENG, CS#1

15.8шт.

GROUP, a/c

1шт.

Indicates part of an assembly

1шт.

See Fig. 02-008

1шт.

BN314933

HARNESS

group, engine, elec.

1шт.

PKG., battery assy.

1шт.

Indicates part of an assembly

1шт.

See Fig. 03-070

1шт.

7

MOUNT, solenoid, w/shield

1шт.

See Fig. 03-068

1шт.

8

BN322891

WIRE HARNESS

HARNESS, CDC 200 engine

1шт.

ns

BN314936

HOSE, BULK

HOSE, METERS DELIVERY, system fuel

1шт.

BN313523

SLEEVE

hose, nylon, 6"

1шт.

BN320236

PKG., HDWE., fuel filter, MTG.

1шт.

BN318839

FUEL HOSE,9.53 mm ID x 3937.00 mm, SAE 30R6, SAE 30R7

fuel 3/8" x 155"

2шт.

BN75906

CLAMP

hose, adj., 3/8 to 1/2, S

1шт.

BN76094

HOSE CLAMP

SS #M4

3шт.

J935740

BANJO BOLT

BANJO

1шт.

GROUP, engine mounts

1шт.

See Fig. 03-062

1шт.
