Запчасти Case IH SPX3200 (06-030) - PRODUCT PUMP GROUP, HYDRAULIC (78) - SPRAYING

1

BN322973

HOSE

10 x 38"

1шт.

2

BN53589

FITTING

10MJ-8MB x 90

1шт.

3

BN21243

PLUG

Hex, 7/8"-14, O-Ring

1шт.

4

218-5123

ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB

1шт.

5

BN315409

HOSE ASSY.

12 x 50"

1шт.

6

BN319839

HOSE

12 x 124"

1шт.

7

BN320158

HYDRAULIC VALVE

DUMP, flow control

1шт.

8

BN51599

ELBOW

90º, 7/8-14, O-RING X 7/8

1шт.

9

BN444007

O-RING

37 Flare 12-10

1шт.

10

BN66219

FITTING

12MJ-8MB

1шт.

11

BN446020

ELBOW

90 degree swivel

1шт.

12

BN300488

WASHER

M6, Flat, 8.8

2шт.

13

86508570

BOLT,Hex, M6 x 80mm OAL, Cl 8.8

2шт.

14

353308

NUT,M6 x 1.0, Cl 8

2шт.

15

BN53573

TEE

FT, JIC-1 1/16, ML-FML

1шт.

16

BN53949

HOSE

3/4" ID x 42" 100R2

1шт.
