Запчасти Case IH SPX3200 (06-029) - HYD GROUP, PRODUCT PUMP (78) - SPRAYING

BN300488

WASHER

M6, Flat, 8.8

2шт.

86508570

BOLT,Hex, M6 x 80mm OAL, Cl 8.8

2шт.

353308

NUT,M6 x 1.0, Cl 8

2шт.

1

BN319010

HOSE

10 x 23"

2шт.

2

BN53589

FITTING

10MJ-8MB x 90

1шт.

3

BN21243

PLUG

Hex, 7/8"-14, O-Ring

1шт.

4

218-5123

ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB

1шт.

5

BN315409

HOSE ASSY.

12 x 50"

1шт.

6

BN315410

HOSE ASSY.

12 x 108"

1шт.

7

BN320158

HYDRAULIC VALVE

DUMP, flow control

1шт.

8

BN315950

FITTING

10MJ-10MB x 90LL

1шт.

9

BN444007

O-RING

37 Flare 12-10

1шт.

10

BN319003

REDUCER FITTING

EXP., 8MB10FMB

1шт.

11

BN51599

ELBOW

90º, 7/8-14, O-RING X 7/8

1шт.

12

BN53573

TEE

FT, JIC-1 1/16, ML-FML

1шт.

13

BN322552

REDUCER

JIC-12F-10M

1шт.
