Запчасти Case IH SPX3200 (09-005) - FRONT PLUMBING GROUP Liquid Plumbing

Схема запчастей Case IH SPX3200 - (09-005) - FRONT PLUMBING GROUP Liquid Plumbing
3
1
29
20
9
4
11
8
4
24
21
18
2
28
5
27
27
14
15
7
10
12
13
6
22
30
17
16
14
19
26
25
27
23
26
6

Артикул

Название

Примечание

Количество

1

BN73781

FITTING,2" Male NPT x 2" Hose Barb, Poly

2" NPT x 2" Hose Barb

1шт.

2

BN303191

TEE,2" Flange x 2" Flange x 1" Flange, Poly

2" Flange X 1" Flange

1шт.

3

405781A1

FITTING,2" Flange x 2" 90 Degree Hose Barb Elbow

2" Flange X 2" Hose Barb, Poly

1шт.

4

BN303199

CLAMP,2" Flange

2" Standard Flange

3шт.

5

BN303203

CLAMP,1" Flange

1" Flange Manifold

1шт.

6

BN303204

GASKET,1-1/2" EPDM Gasket

2" Flange, EPDM

3шт.

7

408350A1

MANIFOLD GASKET,1" EPDM Manifold Gasket

1" x 7/32" thick

1шт.

8

BN304328

VALVE,2" FP Valve w/C-Flng & T Handle

Ball, 2" Flange, W/T Handle

1шт.

9

BN318772

HOSE,0.25" ID x 126.50"

EPDM

1шт.

10

BN319035

HOSE,0.75" ID x 46.00"

Sight gauge

1шт.

11

405793A1

PLUG,1" Flange Plug with 1/4" FPT

1" Manifold x 1/4" FPT, Poly

1шт.

12

BN53433

FITTING

HB, 1/4"NPT X 1/4" HS, STL

1шт.

13

BN53475

ELBOW,90 Degree Elbow, 1" Male NPT x 1" Hose Barb, Poly

1" NPT x 1" Hose Barb, Poly

1шт.

14

BN53682

ELBOW

90-Street-1" Poly

2шт.

15

BN53734

ELBOW

90° 1/4" NPT x 9/16" JIC

1шт.

16

BN53479

HOSE,1.00" ID BULK

EPDM Discharge, Start Serial: 5482

1шт.

Cut 96" from bulk roll

1шт.

17

BN67392

HOSE

3/8" x 144" EPDM

1шт.

18

BN73412

ELBOW,90 Degree,1/4" MPT x 1/4" HB

1/4" NPT x 1/4" Hose Barb, Poly

1шт.

19

BN73562

FITTING,3/4" Male Thread x 3/4" 90 Degree Hose Barb

3/4" NPT x 3/4" Hose Barb, 90°, Start Serial: 5953

1шт.

19

BN73561

FITTING

Barb, 3/4NPT X 3/4HS

1шт.

Indicates Old Part Number Or Can Order Newer Part Number Listed Above

1шт.

20

BN324588

VALVE

Ball 3/4" SU Poly, Start Serial: 5953

1шт.

20

BN73564

VALVE

3/4" Ball Poly 2 Way

1шт.

Indicates Old Part Number Or Can Order Newer Part Number Listed Above

1шт.

21

BN73606

CAP

1" NPT, Poly Pipe

1шт.

22

BN73649

NIPPLE,1" x 3/4" Poly Reducing Nipple

1" x 3/4" Poly

1шт.

23

BN73684

ELBOW

90° 1" MPT x 3/4" Barb

1шт.

24

BN73789

FITTING

Elbow, 2" 90 Degree Poly

1шт.

25

BN75990

HOSE CLAMP

#16, Stainless Steel

1шт.

26

BN75978

HOSE CLAMP

SS, No. 12 adj., HS, .56-1.25

2шт.

27

BN310449

CLAMP,50mm - 65mm

#32, Stainless Steel

2шт.

28

87265393

2" X 42", EPDM, Wire

1шт.

29

BN73793

ELBOW,45 Degree Elbow, 2" Female NPT x 2" Female NPT, Poly

45 STR-2" NPT Poly

1шт.

30

BN72280

LUBE NIPPLE

1 x Close BI, Start Serial: 5391

1шт.

Выбрано товаров: 35
