(10-001) - INTERIOR DECALS

Запчасти Case IH SPX3200 (10-001) - INTERIOR DECALS (13) - DECALS

Схема запчастей Case IH SPX3200 - (10-001) - INTERIOR DECALS (13) - DECALS
12
11
5
9
4
18
2
1
24
23
14
22
13
25
20
8
16
10
19
17
7
15
21
6
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87535740

DECAL

electrical shock

1шт.

2

BN324389

DECAL

Hand Control

1шт.

3

333095A1

DECAL

start and shift

1шт.

4

333096A1

DECAL

boom/wheel tread

1шт.

5

BN69137

DECAL

RH Lite Bar-Dash

1шт.

6

BN69138

DECAL

LH Lite Bar-Dash

1шт.

7

BN69139

DECAL

RH Lite Switch-Dash

1шт.

8

BN69140

DECAL

LH Function Switch-Dash

1шт.

9

BN69141

DECAL

Ignition-Dash

1шт.

10

BN69142

DECAL

Turn Signal - Dash

1шт.

11

BN310442

DECAL

Boom Shutoff

1шт.

12

BN310440

DECAL

Boom Function (Upper)

1шт.

13

BN310441

DECAL

Boom Function (Lower)

1шт.

14

BN69146

DECAL

Boom (Open-Close) Dash

1шт.

15

BN69147

DECAL

Speed Control-Dash

1шт.

16

BN69148

DECAL

Foamarker (Mn-Mx)-Dash

1шт.

17

BN315660

DECAL

Pump, Spring, P2, Axle

1шт.

18

BN315682

DECAL

axle-out, and P1 (aim)

1шт.

19

86986075

DECAL

Electrical 781D

1шт.

20

BN69489

DECAL

Pressure Line Info-NCB

2шт.

21

BN313612

DECAL

Auxiliary 1, Battery Power

1шт.

22

BN315619

DECAL

Switch Powr-Battery

1шт.

23

BN63916

DECAL

Foam Marker

1шт.

24

BN69616

DECAL

fuse & relay boom center

1шт.

25

87270293

DECAL

Weight Warning

1шт.
