Запчасти Case IH SPX3200 (01-003) - AIR SEAT GROUP, SST, 961/2 Cab Interior

1

87268234

RISER

Seat Assembly

1шт.

2

496-21041

WASHER,13/32" x 13/16" x .089", HDN

6шт.

3

86500692

BOLT,Hex, 3/8" - 16 x 3/4", Gr 8, Full Thd

6шт.

4

87268217

ADAPTER

seat, Sears

1шт.

5

86624185

WASHER,8.8mm ID x 17.5mm OD x 2mm Thk

8шт.

6

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

8шт.

7

87268230

DRIVER SEAT

SST Air, 9535 Gray

1шт.

8

87268224

WIRE HARNESS

Seat Power, Sears

1шт.
