Запчасти Case IH SPX3185 (02-010) - CAB EXTERIOR - A/C HOSE KIT Cab Exterior

1

BN313002

HOSE

ASSEMBLY, w/O-ring, A.C.

1шт.

1a

9827059

O-RING,1.78mm Thk x 14mm ID, 70 Duro

1шт.

Part available only through Case's Global After Sales Organization.

1шт.

1b

189819A1

O-RING,1.78mm Thk x 17mm ID

11/16 ID, HNBR, blk

1шт.

Part available only through Case's Global After Sales Organization.

1шт.

2

BN310620

HOSE ASSY.

w/O-ring, A.C.

1шт.

2a

9827059

O-RING,1.78mm Thk x 14mm ID, 70 Duro

1шт.

Part available only through Case's Global After Sales Organization.

1шт.

2b

BN312145

JAM NUT

jam1, 1/16-14

1шт.

2c

BN312146

WASHER

1.07 x 1.31 x .06

1шт.

3

BN311012

FLEXIBLE HOSE

w/ O-ring (A.C.)

1шт.

3a

128483A1

O-RING,1.78mm Thk x 7.65mm ID, 70 Duro

5/16 id x 1/16

1шт.

Part available only through Case's Global After Sales Organization.

1шт.

3b

9827058

O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro

1шт.

Part available only through Case's Global After Sales Organization.

1шт.

3c

9827059

O-RING,1.78mm Thk x 14mm ID, 70 Duro

1шт.

Part available only through Case's Global After Sales Organization.

1шт.

4

BN67787

HOSE

w/ O-Ring (A.C.)

1шт.

4a

128483A1

O-RING,1.78mm Thk x 7.65mm ID, 70 Duro

5/16 id x 1/16

2шт.

Part available only through Case's Global After Sales Organization.

1шт.

5

BN67794

HOSE

w/ O-Ring (A.C.)

1шт.

5a

128483A1

O-RING,1.78mm Thk x 7.65mm ID, 70 Duro

5/16 id x 1/16

1шт.

5b

BN312537

WASHER

jam, 5/8-18

1шт.

5c

BN312538

WASHER

1шт.

6

BN67791

HOSE

w/ O-Ring (A.C.)

1шт.

6a

128483A1

O-RING,1.78mm Thk x 7.65mm ID, 70 Duro

5/16 id x 1/16

2шт.

Part available only through Case's Global After Sales Organization.

1шт.
