Запчасти Case IH SPX2130 (01-002) - CONTROL PANEL Cab Interior

1

BN63712

FLASHER SWITCH

Dual rate w/handle

1шт.

1a

BN63837

Assembly-Wire-Signal Light

1шт.

Associated Part Of Flasher, P/N BN63712

1шт.

1b

BN63838

Assembly-Wire-Signal Light

1шт.

Associated Part Of Flasher, P/N BN63712

1шт.

2

BN63836

Panel Light(Green)

1шт.

3

326944A1

HOURMETER

LCD, 12V

1шт.

3a

BN63935

Assembly-Wire-Red-Hour Meter

1шт.

Associated Part Of Hourmeter LCD 12V, P/N 326944A1

1шт.

3b

BN63936

Assembly-Wire-Black-Hourmeter

1шт.

Associated Part Of Hourmeter LCD 12V, P/N 326944A1

1шт.

4

BN67305

TACHOMETER

0-4000

1шт.

4a

BN301813

BULB

12 V

1шт.

Service Parts For Ref. 4

1шт.

4b

BN301814

SOCKET

Light

1шт.

Service Parts For Ref. 4

1шт.

4c

BN301815

LIGHT

Filter, Lamp, Green

1шт.

Service Parts For Ref. 4

1шт.

6

BN63836

Assembly-Panel Light (Green) AWS Only

1шт.

7

BN67304

ELECTRICAL GAUGE

Volt 12V DC/10-16

1шт.

7a

BN301818

BULB

12V (1.12" Long)

1шт.

Service Parts For Ref. 7

1шт.

8

BN67303

ELECTRICAL GAUGE

Oil Press. 100 PSI

1шт.

8a

BN301818

BULB

12V (1.12" Long)

1шт.

Service Parts For Ref. 8

1шт.

9

BN67302

ELECTRICAL GAUGE

Temp 280 Degree 12V.NG

1шт.

9a

BN301818

BULB

12V (1.12" Long)

1шт.

Service Parts For Ref. 9

1шт.

10

NSS

NOT SOLD SEPARAT

Control-Shift & Throttle, See Fig 01-003

1шт.

11

BN29446

SWITCH

Toggle, On-Off

3шт.

12

342465A1

SWITCH

range select

1шт.

12a

BN29440

KNOB

for Contact Block BN29439

1шт.

Associated Part Of Switch (Speed Range), P/N BN29439

1шт.

13

BN29445

SWITCH

On-Off-On

6шт.

14

BN73516

PLUG

.5" Plastic-Black

3шт.

15

BN29273

SWITCH

Headlight/Taillight

1шт.

16

BN16163

SWITCH

Lighted On - Off

1шт.

18

BN27461

GAUGE

Pressure 0-60 psi

1шт.

19

BN29266

SWITCH

Windshield Wiper

1шт.

20

BN98104

ELECTRICAL GAUGE

160 PSI Panel Mount

2шт.

20a

BN53733

ADAPTER

1/4 npt x 9/16 jic

2шт.

Associated Part Of Gauge-160 PSI Panel Mount, P/N BN98104

1шт.

21

282775A1

IGNITION SWITCH

With Padded Keys

1шт.

21a

BN98413

IGNITION KEY

(2)-Patriot

1шт.

Associated Part Of Switch-Ignition W/Keys (2), P/N BN29278

1шт.

21b

BN29279

For Key

1шт.

Associated Part Of Switch-Ignition W/Keys (2), P/N BN29278

1шт.

21c

BN29280

For Key Switch

1шт.

Associated Part Of Switch-Ignition W/Keys (2), P/N BN29278

1шт.

22

BN29523

ELBOW

Fitting - Electric-Liquid Tight

1шт.

23

BN67301

FUEL GAUGE

Level 12V.N.G.

1шт.

23a

BN301818

BULB

12V (1.12" Long)

1шт.

Service Parts For Ref. 23

1шт.

24

BN29465

GAUGE

Restriction Indicator-Air Filter

1шт.
