Запчасти Case IH 160 (39.100.14) - SUSPENDED BOOM - INNER WING BOOM CONNECTION (39) - FRAMES AND BALLASTING

1

87414

LUBE NIPPLE,1/4" - 28

4шт.

2

87415

LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive

14шт.

3

280161

BOLT,Hex, 3/8" - 16 x 3", Gr 5

2шт.

4

87339

BOLT,Hex, 1/2" - 13 x 3", Gr 5

2шт.

5

88902

NUT,3/8"-16

14шт.

6

86992215

LOCK NUT,1/2"-13, GC

7шт.

7

87325446

WASHER,1.75" ID x 2.5" OD x 0.07" Thk

1 3/4" id 2 1/2" x 14 ga

2шт.

8

87936

BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5

2шт.

9

3326

PIN

cylinder 1" x 2 7/8" ul hardened with snap rings

14шт.

10

87374

WASHER,1.06" ID x 2.5" OD x 0.17" Thk

4шт.

11

87019495

SNAP RING,#98, Ext

36шт.

12

87334418

WASHER,1.5" ID x 2.25" OD x 0.07" Thk

1 33/64" id 2 1/4" 14ga

6шт.

13

87446383

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 304.8mm Stroke

3 1/2" x 12" Monarch 3000 psi

2шт.

Refer to 35.116.05

1шт.

14

87506278

GUIDE

cable hoop

2шт.

15

87443280

BOOM

inner LH

1шт.

16

87443265

LINK

lower hinge lt

1шт.

16

87502058

LINK

lower hinge rt

1шт.

Not Shown

1шт.

17

87443261

LINK

upper hinge

2шт.

18

87449749

PIN

25.4 mm x 127 mm long snap ring grooves

2шт.

19

87449755

PIN

38.1 mm x 214 mm long single hole retention

2шт.

20

87449757

PIN

38.1 mm x 367 mm long single hole retention

2шт.

21

87449753

PIN

44.5 mm x 330 mm long single hole retention

2шт.

22

280286

NUT,1"-8, GB

2шт.
