Запчасти Case IH 100 (39.100.39) - TANK - ASSEMBLY, CART (39) - FRAMES AND BALLASTING

1

87577723

LID

tank hinged 16"

1шт.

Includes 9165, 9162, 9167, 9164, 9159, 9158, 9166, 9163 and 9161

1шт.

2

21908

LID

tank no vent

1шт.

Optional

1шт.

Includes 21700, 21908, 23505 and 87501355

1шт.

Refer to 88.100.04

1шт.

3

22599

TANK

hand/eye wash

1шт.

Includes 7743, 8188 and SQ-193

1шт.

4

87423615

TANK

poly 1600 us gallons (6100 liters)

1шт.

Includes 21700, 87423614 and 87577723

1шт.

4

87438573

TANK

poly 1000 us gallons (3800 liters)

1шт.

Includes 21700, 87438571 and 87577723

1шт.

5

87502258

FRAME

induction tank

1шт.

6

87501966

FRAME

hand/eye wash

1шт.

7

88011

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

3шт.

8

88346

BOLT,Hex, 5/16" - 18 x 2 1/2", Gr 5

1шт.

9

80681

LOCK WASHER,5/16"

2шт.

10

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

11

87972

BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 5

2шт.

12

280736

NUT,5/16"-18, GC

12шт.

13

88902

NUT,3/8"-16

5шт.

14

86992215

LOCK NUT,1/2"-13, GC

4шт.

15

80664

WASHER,0.38" ID x 0.88" OD x 0.08" Thk

14шт.

16

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

3шт.

17

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

2шт.

18

88964

BOLT,Hex, 5/16" - 18 x 4", Gr 5

9шт.

19

87451443

BAR

suction manifold mount

1шт.

20

87504912

STRAP

polyester 2" x 60"

1шт.

21

87502170

BAR

ball valve mount

1шт.

22

364318A1

ANCHOR

for 1 3/4" tank strap

2шт.

100

87578624

REPAIR KIT

sprayer tank dove gray

1шт.

101

87750740

DECAL

CASEIH logo

2шт.

Not Shown

1шт.
