Запчасти Case IH 100 (00.100.04) - DEALER STOCKING LIST (00) - GENERAL & PICTORIAL INDEX

1

87504898

LID

tank vented

1шт.

2

87558402

ADAPTER

solenoid relay 4 pin

1шт.

3

87558392

AGITATOR

jet type 36743, polypropylene

1шт.

4

6975

BUSHING,44.5mm ID x 52.43mm OD x 12.7mm L

windscreen pivot

5шт.

5

406041A1

CLAMP,58.51mm

1" flange banjo #fc100

1шт.

7

86990856

FITTING,2" Flange x 1-1/4" Hose Barb

2" manifold x 1 1/4" barb

1шт.

8

87451446

FITTING

poly flange manifold

1шт.

9

87502088

FITTING,1" Flange x 1" Male Thread

poly 1" mpt x 1" flange

1шт.

10

87502115

COUPLING,1-1/2" Poly Pipe Coupling

poly 1 1/2" fpt coupling

1шт.

11

87502116

PLUG,1" Flange Plug

poly 1" flange cap

1шт.

12

87504874

NIPPLE,1/4" Short Poly Nipple

poly nipple 1/4" mp x 1/4" mp

1шт.

13

87558397

COUPLING,1" Poly Pipe Coupling

poly coupler 1fp

2шт.

14

405783A1

FITTING,2" Flange x 1-1/4" 90 Degree Hose Barb Elbow

poly 90º 2" flange x 1 1/4" hose barb

1шт.

15

405798A1

STRAINER ELEMENT,AAH

fitting poly y 2" line 80 mesh

1шт.

16

24101

FLOAT

7/8" x 2 1/2" polyethylene

2шт.

17

21910

GASKET,33.53mm ID x 45.72mm OD x 3mm Thk

nozzle 1 5/16" id 1 51/64" od 3/16"

2шт.

18

BN303204

GASKET,1-1/2" EPDM Gasket

2" Flange, EPDM

2шт.

19

87413267

GASKET,2" EPDM Gasket

strainer

2шт.

20

408350A1

MANIFOLD GASKET,1" EPDM Manifold Gasket

1" x 7/32" thick

2шт.

21

6042

GASKET

bulkhead fitting

2шт.

22

1027681

GASKET

rubber

2шт.

23

9861

GASKET

rubber

2шт.

24

87558400

HALF-BUSHING

molded 2 3/8" id

5шт.

25

412772A1

KIT

hub bearing completion h817

1шт.

26

6511

KIT

hub bearing completion h411-h511

1шт.

27

7672

KIT

hub bearing completion - h1010

1шт.

28

36727

OIL SEAL,38.1mm ID x 59.28mm OD x 13.11mm Thk

H411 & H511 hub

2шт.

29

87502027

HYDRAULIC PUMP

centrifugal hm1c

1шт.

29

87502027R

REMAN-HYD PUMP

100, 160, Both PRECISION SPRAY FIELD SPRAYER, centrifugal hm1c (11/08-)

1шт.

29

87502027C

CORE-HYDRAULIC PUMP

Return Number

1шт.

30

4198

IMPELLER

pump Hypro* 9203c & 9303c

1шт.

31

8401

BODY

nozzle assembly double

5шт.

32

87558399

BODY

nozzle assembly combo-jet single

5шт.

33

87558396

BODY

nozzle swivel jet

5шт.

34

4639

DIAPHRAGM

nozzle

5шт.

35

87558394

DIAPHRAGM

nozzle for check valve body

5шт.

36

4595

CAP

nozzle quick red

5шт.

37

87558393

CAP

nozzle quick white

5шт.

38

8408

O-RING,13 mm x 3 mm

nozzle seal combo-jet

5шт.

39

8409

FILTER STRAINER,Snap-In C/J, 50 Mesh Red

nozzle 50 mesh

5шт.

33

8407

FILTER STRAINER,Snap-In C/J, 100 Mesh Red

nozzle 100 mesh

5шт.

41

87558391

FILTER STRAINER,Flanged, 100 Mesh

nozzle 100 mesh

5шт.

42

4312

TIP

nozzle xr8003vs

5шт.

43

87558395

TIP

nozzle xr8002 vs

5шт.

44

4310

TIP

nozzle xr80015vs

5шт.

45

4309

TIP

nozzle xr8001vs

5шт.

46

8419

CAP,Combo-Jet Tip/Cap Assy - ER80-04, Red

nozzle tip er80-04 red

5шт.

47

8418

CAP,Combo-Jet Tip/Cap Assy - ER80-03, Blue

nozzle tip er80-03 blue

5шт.

48

8417

CAP,Combo-Jet Tip/Cap Assy - ER80-02, Yellow

nozzle tip er80-02 yellow

5шт.

49

8416

CAP,Combo-Jet Tip/Cap Assy - ER80-015, Green

nozzle tip er80-015 green

5шт.

50

8415

CAP,Combo-Jet Tip/Cap Assy - ER80-01, Orange

nozzle tip er80-01 orange

5шт.

51

8411

CAP,Combo-Jet Tip/Cap Assy - ER110-015, Green

nozzle tip er110-015 green

5шт.

52

8420

ADAPTER,Adapter Assy

teejet body to combojet tip/cap

5шт.

53

23231

ADAPTER,Adapter Assy

combojet body to teejet tip/cap

5шт.

54

87502352

NOZZLE

tip/cap/preo mr80-015

5шт.

55

23671

CAP,Dr Combo-Jet Tip/Cap Assy - Dr80-015, Green

nozzle tip dr80-015 green

5шт.

56

87558403

CAP

nozzle tip preorf dr80-01 cj

2шт.

57

87577652

O-RING

pump centri

5шт.

58

87501994

PANEL

rear rr 50" windscreen

1шт.

59

87501996

PANEL

rear lr 47" windscreen

1шт.

60

87501997

PANEL

front rf 47" windscreen

1шт.

61

87501995

PANEL

front lf 47" windscreen

1шт.

62

8321

PANEL

windscreen 30" rear poly

2шт.

63

8483

PANEL

windscreen 20" rear poly

2шт.

64

8481

PANEL

windscreen 20" front poly

5шт.

65

8484

PANEL

windscreen 17" rear poly

5шт.

66

8482

PANEL

windscreen 17" front poly

5шт.

67

87501998

PANEL

rear rr 47" windscreen

1шт.

68

87501992

PANEL

rear lr 50" windscreen

1шт.

69

87501993

PANEL

front rf 50" windscreen

1шт.

70

87501991

PANEL

front lf 50" windscreen

1шт.

71

87558398

PANEL

windscreen 30" front poly

5шт.

72

87525032

SEAL

pump centrifugal sil carbide

1шт.

73

87446381

SHOCK ABSORBER

1 5/8" bore

2шт.

75

3020

FILTER STRAINER,Flanged, 50 Mesh

nozzle, 50 mesh, red

5шт.

76

87504804

TAPE

Teflon gas yellow 1/2" x 40' roll

5шт.

77

8495

TUBE

square aluminum 29/64" x 59 5/8"

2шт.

78

87504866

TUBE,1692 mm L

square aluminum 119 mm x ong 1692 mm L

2шт.

79

87504867

TUBE,1616 mm L

square aluminum 11.9 mm x ong 1616 mm L

2шт.

80

87501989

TUBE,1263.7 mm L

square aluminum 11.9 mm x ong 1263.7 mm L

2шт.

81

87501990

TUBE,1187.5 mm L

square aluminum 11.9 mm x ong 1187.5 mm L

2шт.

82

87505108

VALVE

elec pressure reg 344b

1шт.

83

8317

BRACKET

windscreen panel mount LH

5шт.

84

22544

BRACKET

windscreen panel mount RH

5шт.

85

8353

CLAMP,33.401mm ID

windscreen panel mount bracket

2шт.

86

1960

GLUE

pvc 10 fl ounces

2шт.
