Запчасти Case IH PATRIOT 4440 (25.100.AA[02]) - REAR AXLE ASSY, RH (25) - FRONT AXLE SYSTEM

Схема запчастей Case IH PATRIOT 4440 - (25.100.AA[02]) - REAR AXLE ASSY, RH (25) - FRONT AXLE SYSTEM
14
34
26
15
7
39
9
21
12
27
16
13
36
24
19
19
29
3
35
20
8
1
2
6
10
11
38
5
7
28
25
4
17
32
7
7
22
37
33
30
31
23
18

Артикул

Название

Примечание

Количество

1

87721676

AXLE

Right Front

1шт.

2

87265738

SLIDE

Axle Adjustment, Right Front

1шт.

3

86986933

THRUST WASHER,95mm ID x 149mm OD x 6.26mm Thk

95mm ID, 149mm OD

1шт.

4

86986935

STEERING ARM

Steering, Right Hand

1шт.

5

BN312604

SPACER

Shim - Axle

1шт.

6

BN302052

WASHER,20.32mm ID x 139.7mm OD

.38mm, 1.75mm

1шт.

7

87529307

WASHER,22mm ID x 37mm OD x 4mm Thk

22mm x 37mm x 4mm, DOR

6шт.

8

87342019

BOLT,Hex, M20 x 2.5 x 40mm, Class 10.9, Full Thd, DOR

1шт.

9

BN302051

NIPPLE, LUBE,M8 x 1, Straight

3шт.

10

BN69951

CAP

Grease

3шт.

11

1316827C1

BUSHING,25.4mm ID x 41.27mm OD x 22.23mm W

2шт.

12

BN301998

DOWEL

Hollow

1шт.

13

87540210

SLIDE

Bar, Axle Slide

1шт.

14

87342045

BOLT,Hex, M20 x 2.5 x 55, Class 10.9, DOR

1шт.

15

BN320759

STOP

Axle Adjust Slide

1шт.

16

892-11020

LOCK WASHER,M20

1шт.

17

87635862

BOLT,Hex, M20 x 35mm, Cl 10.9

M20 x 35mm, Full, Class 10.9

1шт.

18

342939A1

SLEEVE

Dowel, Hollow

2шт.

19

87268646

BOLT,M20 x 2.5 x 100mm, Cl 12.9

M20 - 2.5 x 100mm, 12 PT

2шт.

20

87024336

NUT,M20 x 2.5, Cl 10

2шт.

21

343883A1

SEAL,90mm ID x 110mm OD x 8mm Thk

90mm ID, 110mm OD

1шт.

22

87342001

BOLT,Hex, M20 x 90, Class 10.9, DOR

2шт.

23

87266807

MOUNTING PLATE

Hose Pivot

1шт.

24

BN325088

STOP

Hose

1шт.

25

BN321286

BRACKET

Hose Support, Right Front

1шт.

26

87376798

BUSHING

Hose Pivot

1шт.

27

87266809

SPACER,21.2mm ID x 25.4mm OD x 28mm L

Tube

1шт.

28

87310608

WASHER,22mm ID x 44mm OD x 5mm Thk

22mm x 44mm x 5mm, DOR

1шт.

29

86980460

BOLT,Hex, M20 x 60mm, Cl 8.8

M20 x 60mm, Full 8.8 DOR

1шт.

30

BN313618

BUSHING,16.15mm ID x 26.42mm OD x 35.05mm L

UHMW

1шт.

31

BN313619

BUSHING,12.7mm ID x 16mm OD x 38.1mm L

Tube

1шт.

32

BN323697

SUPPORT

Hose, Right Front

1шт.

33

87528989

WASHER,12.2mm ID x 30mm OD x 2.5mm Thk

1шт.

34

86980427

BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8

1шт.

35

86980516

NUT,Prev Torque, Hex, M12, 1.75 Pitch, Cl 8, DOR

4шт.

36

86980425

BOLT,Hex, M12 - 1.75 x 50mm, Cl 8.8, DOR

1шт.

37

86980423

BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd

2шт.

38

87341829

BOLT,Hex, M16 x 65mm, Cl 8.8

M16 x 65mm, 8.8 DOR

2шт.

39

86980517

NUT,Hex, M16 - 2, Cl 8.8, DOR

2шт.

Выбрано товаров: 39
