Артикул
Название
Примечание
Количество
1
84490175
MOUNT
Spraybar
7шт.
2
BN29563
HOSE
Bulk 1.25" EPDM, 16' Roll
1шт.
3
86980409
BOLT,Hex, M10 x 1.5 x 90mm, Cl 8.8
2шт.
4
BN67054
CLAMP
Spraybar
8шт.
7
87696867
BOOM,65" Long, 7 Holes, 20/30" Nozzle Spacing
Spraybar, Incl 26 - 28
1шт.
9
87341834
BOLT,Hex, M6 - 1 x 100mm, Cl 8.8, DOR
2шт.
10
48020049
STRAP
4 1/2" Backer
1шт.
11
86980515
NUT,Hex, M10 x 1.5, Cl 8.8, DOR
14шт.
14
86980513
NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR
2шт.
15
84181302
SEALING RING
Spraybar
6шт.
16
87484194
PLATE
Backer, Spraybar Mount
2шт.
17
BN309483
PLATE
Clamp Top
8шт.
18
BN67050
BOLT,1/4"-20 X 3.00", Stainless Steel
16шт.
19
BN55359
LOCK NUT,1/4"-20, SS
16шт.
20
48020744
MOUNT
RH Extended
1шт.
21
BN320156
HOSE CLAMP
#24, SST
4шт.
22
87630099
PLUG,1" SST
Cap For Spraybar
3шт.
23
87630101
FITTING,Tee, PP
1 1/4" MPT x 1 1/4" MPT x 1 1/4" Hose Barb
1шт.
24
87630096
FITTING,QN Hose Shank - 1" SST X 1 1/4" Straight Shank
Straight, 1" Flange x 1 - 1/4" Hose Barb
2шт.
25
87630102
FITTING,Adapter Coupler Body - TWS X 1 1/4" NPT FE
Coupler, 1 - 1/4" FPT x 1 - 1/4" Acme
2шт.
26
87630105
NUT
Nut, Quick, Spraybar
6шт.
27
87630103
FITTING
Binding Ring, Spraybar
6шт.
28
87630104
FITTING,TWS Male End Adapter Assy - 1.315" Tube
Split Sleeve, Spraybar
6шт.
Выбрано товаров: 28
