Запчасти Case IH PATRIOT 4440 (78.110.AC[06.1]) - MAIN STRAINER FILTER, ASN YGT042518 (78) - SPRAYING

1

47646606

FILTER STRAINER,STRAINER, FILTER, 2.2FLB,

2" Flange, No Screen

1шт.

2

47888706

GASKET,56mm ID x 83mm OD 5mm Thk

2шт.

3

BN313773

CLAMP,2" Full Port

2шт.

4

84313733

MOUNTING PLATE

Strainer

1шт.

5

47421490

FITTING,2" Full Port Flange x 2" 45 Degree Hose Barb Elbow

45°, 2" Flange x 2" Hose Barb

1шт.

6

BN50146

WASHER,3/8", Stainless

2шт.

7

87342763

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

2шт.

8

87706928

SCREEN,10 SS Mesh Screen

10 Mesh

1шт.
