Запчасти Case IH PATRIOT 3340 (55.015.AB[02]) - ENGINE WIRE HARNESS, BSN YGT044001, PART II (55) - ELECTRICAL SYSTEMS

1

47681355

WIRE HARNESS

Engine T4B, Complete, Incl 2 - 13

1шт.

2

87697770

MULTIPOLE CONNECTOR,Female, 5 Pole

Isolation Relay, X-841F1

1шт.

2

87680656

CONTACT

Female, Tin, Isolation Relay, X-841F1

2шт.

2

87680701

SEAL

Green, Cable, Isolation Relay, X-841F1

4шт.

2

87686742

PLUG

Green, Cavity, Isolation Relay, X-841F1

1шт.

2

87705088

WEDGE

Green, Lock, Isolation Relay, X-841F1

1шт.

2

84179509

RELAY

Miniature, 12V, Isolation Relay, X-841F1

1шт.

3

87312843

FUSE BOX

Female, 50 Pole, External Fuse Relay, X-810F1

1шт.

3

87680656

CONTACT

Female, Tin, External Fuse Relay, X-810F1

12шт.

3

225267C1

TERMINAL CONNECTOR

Female, Tin, External Fuse Relay, X-810F1

6шт.

3

87693249

ELEC. TERMINAL PIN

Female, Tin, External Fuse Relay, X-810F1

4шт.

3

87702660

TERMINAL

Female, Silver, External Fuse Relay, X-810F1

14шт.

3

87680701

SEAL

Green, Cable, External Fuse Relay, X-810F1

13шт.

3

87688859

PLUG,0.8 - 2mm, Red

Red, Cable Seal, External Fuse Relay, X-810F1

3шт.

3

87698530

SEAL

Blue, Cable, External Fuse Relay, X-810F1

15шт.

3

87686742

PLUG

Green, Cavity, External Fuse Relay, X-810F1

12шт.

3

87655334

RELAY,12V, 35A, Micro

12V, 35A, External Fuse Relay, X-810F1

5шт.

3

84127704

FUSE,20A, Mini, Yellow

20A, External Fuse Relay, X-810F1

2шт.

3

84127708

FUSE,30A, Mini, Green

30A, External Fuse Relay, X-810F1

6шт.

3

47600637

DECAL

External Fuse Relay, X-810F1

1шт.

3

47584669

RETAINER

Inside Cover, External Fuse Relay, X-810F1

1шт.

4

84398828

TERMINAL,3/8" Ring, SAE 8

Eyelet, M10, Clean Ground, CG4.1

1шт.

5

84260359

TERMINAL CONNECTOR,Tin, 10.00 - 16.00mm

Ring, M5, Battery Power, PD2.1

1шт.

6

82012083

WIRE CONNECTOR,Female

2 Pole, Intermediate Start, X-806F1

1шт.

6

82012085

TERMINAL CONNECTOR,Female, Tin, 0.75 - 1.5mm

Female, Pre-Tin, Intermediate Start, X-806F1

2шт.

6

82012084

SEAL,1.4mm ID

Yellow, Wire, Intermediate Start, X-806F1

1шт.

6

87406998

SEAL

Red, Wire, Intermediate Start, X-806F1

1шт.

7

82012083

WIRE CONNECTOR,Female

2 Pole, Grid Heater, X-817F1

1шт.

7

87687564

TERMINAL CONNECTOR

Female, Pre-Tin, Grid Heater, X-817F1

2шт.

7

82012084

SEAL,1.4mm ID

Yellow, Wire, Grid Heater, X-817F1

2шт.

8

84127304

TERMINAL

Ring, M5, Alternator Excite, X-835F1

1шт.

8

87710106

TERMINAL CONNECTOR

Red, Boot, Alternator Excite, X-835F1

1шт.

9

84146686

ELEC CONNECTOR,Female, 4 Cavities

Female, 4 Pole, NH3 Sensor, X-831F1

1шт.

9

84152584

TERMINAL,Tin, 0.50 - 1.00mm

Female, Pre-Tin, NH3 Sensor, X-831F1

2шт.

9

87691478

SEAL

Wire, NH3 Sensor, X-831F1

2шт.

10

87709793

WIRE CONNECTOR,Female, 2 Cavities

Female, 2 Pole, SCR Downstream Exhaust Temp, X-828F1

1шт.

10

47399877

TERMINAL

Female, Silver, SCR Downstream Exhaust Temp, X-828F1

2шт.

10

87705976

SEAL

White, Wire, SCR Downstream Exhaust Temp, X-828F1

2шт.

11

87709793

WIRE CONNECTOR,Female, 2 Cavities

Female, 2 Pole, DOC Upstream Temp, X-839F1

1шт.

11

47399877

TERMINAL

Female, Silver, DOC Upstream Temp, X-839F1

2шт.

11

87705976

SEAL

White, Wire, DOC Upstream Temp, X-839F1

2шт.

12

87709793

WIRE CONNECTOR,Female, 2 Cavities

Female, 2 Pole, DEF Dosing Module, X-804F1

1шт.

12

47399877

TERMINAL

Female, Silver, DEF Dosing Module, X-804F1

2шт.

12

87705976

SEAL

White, Wire, DEF Dosing Module, X-804F1

2шт.

13

84190317

WIRE CONNECTOR,Female, 5 Cavities

Female, 5 Pole, NOX Sensor SCR Downstream, X-825F1

1шт.

13

84190318

TERMINAL CONNECTOR

Female, Pre-Tin, NOX Sensor SCR Downstream, X-825F1

1шт.

13

87709655

BLANK-OFF PLUG

Blue, NOX Sensor SCR Downstream, X-825F1

1шт.
