Запчасти Case IH PATRIOT 3340 (55.015.AB[01]) - ENGINE WIRE HARNESS, BSN YGT044001, PART I (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH PATRIOT 3340 - (55.015.AB[01]) - ENGINE WIRE HARNESS, BSN YGT044001, PART I (55) - ELECTRICAL SYSTEMS
20
12
home
22
15
6
4
16
5
10
55.015.ab 02
2
13
19
18
24
1
8
17
7
3
23
14
21
9
11

Артикул

Название

Примечание

Количество

1

47681355

WIRE HARNESS

Engine, T4B, Complete, Incl 2 - 24

1шт.

See 55.015.AB 02 For The Rest Of Harness

1шт.

2

84177901

ELEC CONNECTOR

31 Pole, Male, Engine Interface, XB-801F1

1шт.

2

87697947

ELEC. TERMINAL PIN,Nickel, 0.50 - 1.00mm

Engine Interface, XB-801F1

6шт.

2

225407C1

PIN

Male, Gold, Stamped, Engine Interface, XB-801F1

2шт.

2

84068583

PLUG,12 - 16 Ga, White

Sealing, Engine Interface, XB-801F1

17шт.

2

87700175

ELEC CONNECTOR

Grey, Boot, HD30 Series, Engine Interface, XB-801F1

1шт.

3

84607243

ELEC CONNECTOR,Female, 2 Cavities

Spring Clip, Air Filter Restriction Sensor, X-811F1

1шт.

3

87702681

TERMINAL

Female, Tin, Air Filter Restriction Sensor, X-811F1

2шт.

3

87691478

SEAL

Wire, Air Filter Restriction Sensor, X-811F1

2шт.

3

87691026

CAP

Rubber Boot, Air Filter Restriction Sensor, X-811F1

1шт.

4

87709793

WIRE CONNECTOR,Female, 2 Cavities

SCR Upstream Ex Temp, X-827F1

1шт.

4

47399877

TERMINAL

Female, Silver, SCR Upstream Ex Temp, X-827F1

2шт.

4

87705976

SEAL

White, Single Wire, SCR Upstream Ex Temp, X-827F1

2шт.

5

84190317

WIRE CONNECTOR,Female, 5 Cavities

NOX Sensor 2 DOC Upstream, X-836F1

1шт.

5

84190318

TERMINAL CONNECTOR

Female, Pre-Tin, NOX Sensor 2 DOC Upstream, X-836F1

3шт.

6

87709809

ELEC CONNECTOR

4 Pole, Female, Humidity, Temp, Sensor, X-830F1

1шт.

6

84130602

TERMINAL CONNECTOR

Male, Tin, Humidity, Temp, Sensor, X-830F1

4шт.

6

87705976

SEAL

White, Single Wire, Humidity, Temp, Sensor, X-830F1

4шт.

7

87687239

CONTACT HOUSING,Female, 1 Pole

AC Clutch, X-814F1

1шт.

7

82012085

TERMINAL CONNECTOR,Female, Tin, 0.75 - 1.5mm

AC Clutch, X-814F1

1шт.

7

82012084

SEAL,1.4mm ID

Yellow, Single Wire, AC Clutch, X-814F1

1шт.

8

87688788

MULTIPOLE CONNECTOR,Male, 2 Pole

AC Safety Switch, X-813M1

1шт.

8

87688814

TERMINAL

Male, Tin, AC Safety Switch, X-813M1

2шт.

8

87688859

PLUG,0.8 - 2mm, Red

Cable Seal, AC Safety Switch, X-813M1

2шт.

8

87688862

LOCKING TAB

Black, AC Safety Switch, X-813M1

1шт.

9

84300197

ELEC CONNECTOR

Female, 96 pole, EDC 17, Engine ECU, X-816F1

1шт.

9

84300195

TERMINAL

Female, Silver, Engine ECU, X-816F1

14шт.

9

84300193

LOCK

Secondary Lock, EDC 17, Engine ECU, X-816F1

1шт.

9

84300198

ELEC CONNECTOR

96 Pole Cover, Engine ECU, X-816F1

1шт.

10

87696093

ELEC CONNECTOR,Female, 2 Cavities

ECM Flashing, X-818F1

1шт.

10

87696145

LOCKING TAB

Wedge Lock, ECM Flashing, X-818F1

1шт.

11

87696547

ELEC CONNECTOR,Female, 2 Cavities

2 Pole, Male, Cap, X-818M1

1шт.

11

84807680

PLUG

Red, Sealing, Cap, X-818M1

2шт.

12

84152563

ELEC CONNECTOR

7 Pole, Female, FPT Harness Interface, X-840F1

1шт.

12

87691478

SEAL

Wire, FPT Harness Interface, X-840F1

2шт.

12

82035902

PLUG

Natural, Cavity Plug, FPT Harness Interface, X-840F1

1шт.

12

84129571

PLUG

White, Cavity Plug, FPT Harness Interface, X-840F1

2шт.

13

87679438

WIRE CONNECTOR,Female

2 Pole, Fuel Restriction, X-667F1

1шт.

13

87680656

CONTACT

Female, Tin, Fuel Restriction, X-667F1

2шт.

13

87680701

SEAL

Green, Cable, Fuel Restriction, X-667F1

2шт.

13

84806458

COLLAR

Blue, TPA Lock, Fuel Restriction, X-667F1

1шт.

14

87686736

ELEC CONNECTOR

2 Pole, Male, Fuel Restriction, X-667M1

1шт.

14

84806458

COLLAR

Blue, TPA Lock, Fuel Restriction, X-667M1

1шт.

14

87686742

PLUG

Green, Cavity Plug, Fuel Restriction, X-667M1

1шт.

15

84140737

TERMINAL CONNECTOR

Ring, M10, Ground, G1-DX

1шт.

16

87695723

ELEC CONNECTOR,Male , 3 Pole

Switched Power, X-505M1

1шт.

16

86500035

ELEC. TERMINAL PIN,Male, 0.75 - 2mm

Stamped, Switched Power, X-505M1

2шт.

16

87695623

ELEC. TERMINAL PIN

Male, Nickel, Stamped, Switched Power, X-505M1

1шт.

16

87695625

WIRE CONNECTOR,Locking, Green

Wedge Lock, Switched Power, X-505M1

1шт.

17

87707727

WIRE CONNECTOR

4 Pole, Female, Power Interface, X-506F1

1шт.

17

87695923

TERMINAL

Female, Nickel, Stamped, Power Interface, X-506F1

4шт.

17

87707796

ELEC CONNECTOR

Wedge Lock, Power Interface, X-506F1

1шт.

18

87421341

MULTIPOLE CONNECTOR,Male, 4 Pole

Dust Cap, Power Interface, X-506M1

1шт.

18

84068583

PLUG,12 - 16 Ga, White

Sealing, Dust Cap, Power Interface, X-506M1

4шт.

19

84146685

WIRE CONNECTOR,Female, 3 Cavities

3 Pole, Urea Heater Valve, X-829F1

1шт.

19

84152576

TERMINAL

Female, Pre-Tin, Urea Heater Valve, X-829F1

2шт.

19

84129570

SEAL

Yellow, Wire, Urea Heater Valve, X-829F1

1шт.

19

84129571

PLUG

White, Cavity Plug, Urea Heater Valve, X-829F1

1шт.

20

84062580

CONNECTOR, ELEC

3 Pole, Female, Urea Tank Sensor Interface, X-803F1

1шт.

20

82012085

TERMINAL CONNECTOR,Female, Tin, 0.75 - 1.5mm

Urea Tank Sensor Interface, X-803F1

1шт.

20

87687564

TERMINAL CONNECTOR

Female, Pre-Tin, Urea Tank Sensor Interface, X-803F1

2шт.

20

82012084

SEAL,1.4mm ID

Yellow, Wire, Urea Tank Sensor Interface, X-803F1

2шт.

21

84149219

ELEC CONNECTOR

6 Pole, Female, Quality Sensor, X-837F1

1шт.

21

84152576

TERMINAL

Female, Pre-Tin, Quality Sensor, X-837F1

1шт.

21

84129570

SEAL

Yellow, Wire, Quality Sensor, X-837F1

1шт.

21

84129571

PLUG

White, Cavity Plug, Quality Sensor, X-837F1

2шт.

22

87696547

ELEC CONNECTOR,Female, 2 Cavities

2 Pole, Male,Terminator, X-826M1

1шт.

22

87696585

LOCKING TAB,Wedge Lock, 2-Pin

Wedge Lock,Terminator, X-826M1

1шт.

23

84539353

WIRE CONNECTOR

2 Pole, Female,Terminator, X-826F1

1шт.

24

84152570

ELEC CONNECTOR,Female, 12 Cavities

Denox Supply Module, X-823F1

1шт.

24

84152576

TERMINAL

Female, Pre-Tin, Denox Supply Module, X-823F1

8шт.

24

84129570

SEAL

Yellow, Wire, Denox Supply Module, X-823F1

7шт.

24

84129571

PLUG

White, Cavity Plug, Denox Supply Module, X-823F1

4шт.

24

84567010

COVER

Denox Supply Module, X-823F1

1шт.

Выбрано товаров: 75
