Запчасти Case IH PATRIOT 2250 (10.304.AS[01]) - DIPSTICK & OIL FILL TUBE (10) - ENGINE

1

47884290

MOUNT

Dipstick Tube

1шт.

2

9706748

CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type

2шт.

3

86980379

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

2шт.

4

87529316

WASHER,9mm ID x 21mm OD x 2.5mm Thk

2шт.

5

86980514

LOCK NUT,Hex, M8, Cl 8, DOR

2шт.
