Запчасти Case IH PATRIOT 2250 (05.100.02[02]) - INITIAL STOCKING LIST (LIST B) (05) - SERVICE & MAINTENANCE

1

87519307

SENSOR

Water in Fuel

1шт.

2

84297496

SHOCK ABSORBER

Suspension

1шт.

3

87442359

STARTER MOTOR

Engine

1шт.

4

87000227

SWITCH, A/C HIGH PRE

Atmospheric

1шт.

5

87000228

SWITCH, A/C LOW PRES

Atmospheric

1шт.

6

279492A1

RESTRICTION SWITCH

Air Filter

1шт.

7

47493762

BATTERY CUT-OUT

Battery, Cut-off

1шт.

8

84275431

BEACON SWITCH

1шт.

9

BN321913

SWITCH

Boom Fold, LH

1шт.

10

BN321915

SWITCH

Boom Fold, RH

1шт.

11

87397313

SWITCH

Boom, One Touch Fold

1шт.

12

BN321910

SWITCH

Boom, Section

1шт.

13

87484878

LIMIT SWITCH

Brake Pedal

1шт.

14

83961521

LIGHT SWITCH

Dome Light

1шт.

15

86986404

SWITCH

Emergency Engine Stop

1шт.

16

BN321911

SWITCH

Fence Row

1шт.

17

47783301

ROCKER SWITCH

Foam

1шт.

18

84470559

SWITCH

Foot Pedal

1шт.

19

84294877

SWITCH

Hazard

1шт.

20

84416718

IGNITION SWITCH,50A

50A, Off/Run

1шт.

21

84541429

SWITCH

Main Power

1шт.

22

BN323496

TOGGLE SWITCH

Neutral

1шт.

23

124098A1

SWITCH

Park Brake

1шт.

24

BN315498

SWITCH

Proximity

1шт.

25

86986400

SWITCH

Pressure, PMLF

1шт.

26

87267808

PRESSURE SWITCH

Oil, 25 PSI, N/C

1шт.

27

86400227

SWITCH,Two Connectors, 90° Terminals

Operator Presence

1шт.

28

BN323495

ADAPTER

Reverse

1шт.

29

86986401

SWITCH ASSY

Rotary 4 Position

1шт.

30

BN29445

SWITCH

Toggle (ON) Off (ON)

1шт.

31

84293177

WINDSHIELD WASHER SW

Wiper

1шт.

32

84322388

THERMOSTAT

Engine

1шт.

33

87557834

HYDRAULIC VALVE

C-Balance

1шт.

34

84347992

CHECK VALVE

Check 1-1/4" NPT

1шт.

35

BN304339

VALVE

Hydraulic Oil Tank Breather

1шт.

36

47579021

WIPER ARM

Windshield

1шт.

37

84346694

WIPER BLADE,Single, 500mm L

Windshield

1шт.
