Артикул
Название
Примечание
Количество
1
47937785
PIPE
Spraybar, 4 Hole, 20"/30" Spacing, 54" Long, SCH 80, Poly
1шт.
3
47888704
GASKET,28mm ID x 52mm OD x 5.6mm Thk
1" Flange
8шт.
4
BN310447
HOSE CLAMP
#20, SST
6шт.
5
BN67054
CLAMP
Includes Top and Bottom Halves
4шт.
6
47614661
MOUNT
Spraybar, Outer
2шт.
7
47654165
SPACER
4шт.
8
86980515
NUT,Hex, M10 x 1.5, Cl 8.8, DOR
6шт.
10
BN309483
PLATE
Cover
4шт.
11
86980369
BOLT,Hex, M6 x 80, Cl 8.8
DOR
8шт.
12
86980513
NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR
8шт.
13
BN73606
CAP
1", Poly
2шт.
14
47767363
FITTING,1" x 1" x 3/4" Hose Barb Tee
1" Tee
1шт.
15
BN303203
CLAMP,1" Flange
1" Flange
4шт.
16
BN53479
HOSE,1.00" ID BULK
Cut to Required Length
1шт.
17
47804854
FITTING,1" Flange x 1" Pipe Thread
1" Flange to Spraybar
2шт.
18
BN303194
ELBOW,90 Degree Elbow, 1" Flange x 1" Hose Barb, Poly
3шт.
19
BN304317
PLUG,2" Flange, Poly
1шт.
20
BN306900
FITTING,2" Flange x 1-1/4" Hose Barb, Poly
1шт.
21
BN303199
CLAMP,2" Flange
2шт.
22
BN303204
GASKET,1-1/2" EPDM Gasket
2" Flange, EPDM
2шт.
23
87265462
MOUNTING PARTS
Boom Valve
1шт.
24
84343258
MOUNT
Spraybar, Breakaway
2шт.
25
87452548
PIPE
Spraybar, 3 Hole, 20"/30" Spacing, 46" Long, SCH 80, Poly
1шт.
26
BN50697
BOLT,Hex, 1/4" - 20 x 1/2", SST
2шт.
See 78.110.AB 01 For Service Parts
1шт.
28
47917419
FITTING,90 Degree 1" Flange
90° Flange
1шт.
Выбрано товаров: 28
