Запчасти Case IH PATRIOT 2250 (55.404.BS[02]) - REAR CAB ROOF HALOGEN WORK LIGHT ASSY (55) - ELECTRICAL SYSTEMS

1

87597953

NUT,M8, 1.25 Pitch, 10.6mm High, Cl 8, ZND

2шт.

2

84317198

COVER PLATE

3 Hole

2шт.

3

84187810

SCREW,Torx Pan Hd, M8 x 16mm, Cl 8.8

6шт.

4

84317199

BRACKET

LH

1шт.

5

84317200

BRACKET

RH

1шт.

6

11193879

BELLEVILLE WASHER,M8 Bolt Size x 16mm OD x 1.4mm Thk

4шт.

7

16044534

BOLT,Hex, M8 x 1.25 x 65mm, Cl 10.9

2шт.

8

16102314

THIN NUT,M8 x 1.25, Cl 04

4шт.

9

84317204

BRACKET

Mounting

2шт.

10

825-5148

SERRATED NUT,M8, Flg Ser

2шт.

11

84299527

LAMP,Halogen, 12V, 55W, Clear Lens

12V 55W Halogen

2шт.

See 55.404.BS 03 for Service

1шт.

12

16044221

SCREW,Hex, M8 x 1.25 x 50mm, Cl 8.8

2шт.
