Запчасти Case IH PATRIOT 2250 (41.432.AC[01]) - AUTOGUIDANCE HYDRAULIC LINES (41) - STEERING

1

47636434

VALVE

AutoGuide, Complete

1шт.

See 41.432.AE 01 For Service

1шт.

2

47873104

HYDRAULIC HOSE

11/16-16 ORFS Swivel 90° Elbow Long x 11/16-16 ORFS Swivel 90° Elbow Short, From AutoGuide Valve to Left Front Steering Cylinders

1шт.

3

47873105

HYDRAULIC HOSE

11/16-16 ORFS Swivel 90° Elbow Long x 11/16-16 ORFS Swivel 90° Elbow Short, From AutoGuide Valve to Right Front Steering Cylinders

1шт.

4

BN302436

TEE

13/16 -16 ORFS x 13/16 -16 ORFS Swivel, Incl 13

1шт.

5

84385541

HYDRAULIC HOSE

13/16-16 ORFS Swivel StraightShort x 13/16-16 ORFS Swivel Straight Short, From AutoGuide Valve to Steering Tee

1шт.

6

84385542

HYDRAULIC HOSE

11/16-16 ORFS Swivel Straight Short x 11/16-16 ORFS Swivel 90° Elbow Long, From AutoGuide Valve to Steering Pressure Steel Line

1шт.

7

BN302435

TEE

11/16 -16 ORFS x 11/16 -16 ORFS Swivel Run, Incl 12

2шт.

8

86980513

NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR

2шт.

9

BN570007

STRAP

14"

21шт.

10

86980368

BOLT,Hex, M6 x 1 x 70mm, Cl 8.8

2шт.

11

87529314

WASHER,6.6mm ID x 12.5mm OD x 2mm Thk

2шт.

12

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

4шт.

13

9992298

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

5шт.
