Запчасти Case IH 4430 (90.118.05) - DOOR STOP, RH, BOOM MOUNTED (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

87552355

DOOR

Stop Assembly

1шт.

See Fig 90.118.06 For Service Parts Breakdown

1шт.

2

BN319918

U-BOLT,SQ BND 1.31" ID x 3/8"

BOLT "U" Square Bend 3/8"-16 x 1.31 wide x 2.00 Deep

2шт.

3

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

4шт.
