(90.108.05) - SLOW MOVING VEHICLE SIGN

Запчасти Case IH 4430 (90.108.05) - SLOW MOVING VEHICLE SIGN (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 4430 - (90.108.05) - SLOW MOVING VEHICLE SIGN (90) - PLATFORM, CAB, BODYWORK AND DECALS
7
4
home
5
3
2
1
6
8
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87618518

MOUNT

SMV

1шт.

2

A59457

BRACKET

Socket

1шт.

3

A59450

WARNING SIGN

SMV

1шт.

4

BN50222

BOLT

5/16 - 18 x .75, TH, SS, PH

2шт.

5

BN50057

LOCK NUT,Lock, 5/16"-18, Stainless Steel

2шт.

6

84203615

MOUNT

SMV

1шт.

7

86980406

BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8

2шт.

8

86980515

NUT,Hex, M10 x 1.5, Cl 8.8, DOR

2шт.
