Запчасти Case IH 4430 (55.100.13[01]) - FRAME HARNESS (55) - ELECTRICAL SYSTEMS

1

84488932

WIRE HARNESS

Frame Harness

1шт.

2

87694153

CONTACT HOUSING,Female, 4 Cavities

RH Hydrostat Control, C641F

1шт.

87694146

ELEC CONNECTOR,Locking, Green

Wedge, RH Hydrostat Control, C641F

1шт.

225365C1

SOCKET

RH Hydrostat Control, C641F

4шт.

3

87695582

ELEC CONNECTOR,Female, 2 Pole

RH Hydrostat Control Override, C645F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Wedge, RH Hydrostat Control Override, C645F

1шт.

225365C1

SOCKET

RH Hydrostat Control Override, C645F

2шт.

4

87694153

CONTACT HOUSING,Female, 4 Cavities

LH Hydrostat Control, C639F

1шт.

87694146

ELEC CONNECTOR,Locking, Green

Wedge, LH Hydrostat Control, C639F

1шт.

225365C1

SOCKET

LH Hydrostat Control, C639F

4шт.

5

87695582

ELEC CONNECTOR,Female, 2 Pole

LH Hydrostat Control Override, C646F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Wedge, LH Hydrostat Control Override, C646F

1шт.

225365C1

SOCKET

LH Hydrostat Control Override, C646F

2шт.

6

87695582

ELEC CONNECTOR,Female, 2 Pole

Charge PSI, C638F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Wedge, Charge PSI, C638F

1шт.

225365C1

SOCKET

Charge PSI, C638F

2шт.

7

87695584

CONTACT HOUSING,Male, 2 Cavities

Charge PSI Shoring Cap, C638M

1шт.

87577731

CONTACT HOUSING,2 Pole

Wedge, Charge PSI Shoring Cap, C638M

1шт.

225366C1

ELEC. TERMINAL PIN,Male, Gold, 0.75 - 2.00mm

Charge PSI Shoring Cap, C638M

2шт.

8

12063144

CABLE TERMINAL

Backup Alarm, C608F

1шт.

9

12063144

CABLE TERMINAL

Backup Alarm, C609F

1шт.

10

87695592

CONTACT HOUSING,Female, 12 Pole

Tail Light Harness Interface, C606F

1шт.

87695651

LOCKING TAB,Wedge Lock

Tail Light Harness Interface, C606F

1шт.

84068583

PLUG,12 - 16 Ga, White

Tail Light Harness Interface, C606F

2шт.

225365C1

SOCKET

Tail Light Harness Interface, C606F

10шт.

11

87694153

CONTACT HOUSING,Female, 4 Cavities

Backlight and Worklight, C604F

1шт.

87694146

ELEC CONNECTOR,Locking, Green

Backlight and Worklight, C604F

1шт.

84068583

PLUG,12 - 16 Ga, White

Backlight and Worklight, C604F

1шт.

225365C1

SOCKET

Backlight and Worklight, C604F

3шт.

12

87270520

DIODE

Backlight and Worklight Diode Pack, C604M

1шт.

13

87696075

ELEC CONNECTOR

Splice, CS47FB

1шт.

87695651

LOCKING TAB,Wedge Lock

Splice, CS47FB

1шт.

225365C1

SOCKET

Splice, CS47FB

12шт.

14

87269436

SOCKET/RECEPTACLE

12 Way Splice Pack, CS47MB

1шт.

15

84149204

TERMINAL CONNECTOR

Ground Box, CG-MF

1шт.

16

84177901

ELEC CONNECTOR

Engine Harness Interface, C801M

1шт.

84068583

PLUG,12 - 16 Ga, White

Engine Harness Interface, C801M

15шт.

87697947

ELEC. TERMINAL PIN,Nickel, 0.50 - 1.00mm

Engine Harness Interface, C801M

13шт.

86500035

ELEC. TERMINAL PIN,Male, 0.75 - 2mm

Engine Harness Interface, C801M

1шт.

225366C1

ELEC. TERMINAL PIN,Male, Gold, 0.75 - 2.00mm

Engine Harness Interface, C801M

2шт.

17

87692877

MULTIPOLE CONNECTOR,Male, 2 Cavities

Remote Power, C630M

1шт.

225120C1

TERMINAL CONNECTOR,Tin, 0.8mm

Remote Power, C630M

2шт.

18

87692855

CONTACT HOUSING,Male, 2 Cavities

Auxilary Boom Lights, C627F

1шт.

225123C1

TERMINAL CONNECTOR,Tin, 0.8mm

Auxilary Boom Lights, C627F

2шт.

19

87692877

MULTIPOLE CONNECTOR,Male, 2 Cavities

Cap For Auxilary Boom Lights, DC627

1шт.

87686742

PLUG

Cap For Auxilary Boom Lights, DC627

2шт.

20

225320C1

ELEC CONNECTOR

Remote Engine, C800M

1шт.

225322C1

WEDGE

Remote Engine, C800M

1шт.

84068583

PLUG,12 - 16 Ga, White

Remote Engine, C800M

2шт.

225366C1

ELEC. TERMINAL PIN,Male, Gold, 0.75 - 2.00mm

Remote Engine, C800M

6шт.

21

84176551

ELEC CONNECTOR,16.00 - 16.00mm

Chassis Ground, G1-MF

1шт.

22

87695582

ELEC CONNECTOR,Female, 2 Pole

Axle Out, C613F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Axle Out, C613F

1шт.

225365C1

SOCKET

Axle Out, C613F

2шт.

23

87695582

ELEC CONNECTOR,Female, 2 Pole

Axle In, C614F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Axle In, C614F

1шт.

225365C1

SOCKET

Axle In, C614F

2шт.

24

87695582

ELEC CONNECTOR,Female, 2 Pole

Motor Control, C647F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Motor Control, C647F

1шт.

225365C1

SOCKET

Motor Control, C647F

2шт.

25

87695582

ELEC CONNECTOR,Female, 2 Pole

Reverse Limiter, C632F

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

Reverse Limiter, C632F

1шт.

225365C1

SOCKET

Reverse Limiter, C632F

2шт.

26

87695582

ELEC CONNECTOR,Female, 2 Pole

Park Brake, C631F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Park Brake, C631F

1шт.

225365C1

SOCKET

Park Brake, C631F

2шт.

27

280451A1

CONNECTOR,ELECTRIC

Hydraulic Oil Temp and Level, C628F

1шт.

280454A1

WEDGE

Hydraulic Oil Temp and Level, C628F

1шт.

87698572

PLUG,20 Ga, Red

Hydraulic Oil Temp and Level, C628F

1шт.

223953A1

SOCKET/RECEPTACLE

Hydraulic Oil Temp and Level, C628F

5шт.

28

87692855

CONTACT HOUSING,Male, 2 Cavities

Hydraulic Filter Indicator, C629F

1шт.

225122C1

TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm

Hydraulic Filter Indicator, C629F

1шт.

225123C1

TERMINAL CONNECTOR,Tin, 0.8mm

Hydraulic Filter Indicator, C629F

1шт.

29

87695582

ELEC CONNECTOR,Female, 2 Pole

Traction Control, C643F

1шт.

87695649

ELEC CONNECTOR,Locking, Green

Traction Control, C643F

1шт.

225365C1

SOCKET

Traction Control, C643F

2шт.
