Запчасти Case IH 4430 (55.100.06[01]) - CAB LH COMPARTMENT HARNESS, BSN YCT032413 (55) - ELECTRICAL SYSTEMS
![Схема запчастей Case IH 4430 - (55.100.06[01]) - CAB LH COMPARTMENT HARNESS, BSN YCT032413 (55) - ELECTRICAL SYSTEMS](https://partsell.ru/storage/images/caseih/120789.png)
№
Артикул
Название
Примечание
Количество
1
84281625
HARNESS
Cab Interface/Bulkhead, Connects RH Console Harness To Frame Product Harness
1шт.
2
87705041
MULTIPOLE CONNECTOR,Female, 30 Pole
Relay Panel 6
1шт.
87704921
LOCK
Relay Panel 6
1шт.
182135A1
TERMINAL CONNECTOR
Terminal, Relay Panel 6
3шт.
182128A1
CONNECTOR, ELEC
CONNECTOR Terminal, Relay Panel 6
1шт.
3
86509590
RELAY
20 Amp, Relay Panel 6
1шт.
4
87705041
MULTIPOLE CONNECTOR,Female, 30 Pole
Relay Panel 5
1шт.
87704921
LOCK
Relay Panel 5
1шт.
182135A1
TERMINAL CONNECTOR
Terminal, Relay Panel 5
16шт.
182128A1
CONNECTOR, ELEC
CONNECTOR Terminal, Relay Panel 5
9шт.
5
86509590
RELAY
20 Amp, Relay Panel 5
6шт.
6
87705041
MULTIPOLE CONNECTOR,Female, 30 Pole
Relay Panel 4
1шт.
87704921
LOCK
Relay Panel 4
1шт.
182135A1
TERMINAL CONNECTOR
Terminal, Relay Panel 4
17шт.
182128A1
CONNECTOR, ELEC
CONNECTOR Terminal, Relay Panel 4
8шт.
7
86509590
RELAY
20 Amp, Relay Panel 4
6шт.
8
87705101
MULTIPOLE CONNECTOR,Female, 12 Pole
Propel Node B, C206F
1шт.
87705198
WEDGE
Propel Node B, C206F
1шт.
225039C1
TERMINAL
Propel Node B, C206F
7шт.
87705198
WEDGE
Propel Node A, C205F
1шт.
223953A1
SOCKET/RECEPTACLE
Propel Node A, C205F
2шт.
225039C1
TERMINAL
Propel Node A, C205F
7шт.
87705198
WEDGE
Foam Marker, C204F
1шт.
225039C1
TERMINAL
Foam Marker, C204F
9шт.
11
87692855
CONTACT HOUSING,Male, 2 Cavities
Foam Advance, C202F
1шт.
225122C1
TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm
Foam Advance, C202F
2шт.
12
87692877
MULTIPOLE CONNECTOR,Male, 2 Cavities
Foam Advance Jumper, C202M
1шт.
225119C1
TERMINAL
Foam Advance Jumper, C202M
2шт.
13
87692858
ELEC CONNECTOR,Male
GPS Port, C200M
1шт.
225119C1
TERMINAL
GPS Port, C200M
3шт.
14
87705101
MULTIPOLE CONNECTOR,Female, 12 Pole
Speed Node Keying B, C251F
1шт.
87705198
WEDGE
Speed Node Keying B, C251F
1шт.
223953A1
SOCKET/RECEPTACLE
Speed Node Keying B, C251F
2шт.
225039C1
TERMINAL
Speed Node Keying B, C251F
3шт.
87705198
WEDGE
Speed Node Keying A, C249F
1шт.
87696954
TERMINAL,Female, Nickel, 0.35 - 1.50mm
Speed Node Keying A, C249F
1шт.
225039C1
TERMINAL
Speed Node Keying A, C249F
10шт.
16
87694153
CONTACT HOUSING,Female, 4 Cavities
Product Can, C211F
1шт.
84074640
LOCKING TAB,Wedge Lock
Wedge Locking, Product Can, C211F
1шт.
86500036
TERMINAL,Female, Nickel, 0.75 - 2mm
Product Can, C211F
2шт.
225365C1
SOCKET
Product Can, C211F
2шт.
17
84279551
ELEC CONNECTOR,1.00 - 2.50mm
M12 Stud, CG3
1шт.
18
84140737
TERMINAL CONNECTOR
Chassis Ground, G1 - CM
1шт.
19
87707114
CONTACT HOUSING,Male, 70 Pole
Console Interface, C128M
1шт.
225241C1
SOCKET
Console Interface, C128M
56шт.
20
87716941
MULTIPOLE CONNECTOR,Male, 31 Pole
Hydraulic Bulkhead, CM4M
1шт.
87271930
NUT
Hydraulic Bulkhead, CM4M
1шт.
225241C1
SOCKET
Hydraulic Bulkhead, CM4M
23шт.
86500035
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
Hydraulic Bulkhead, CM4M
1шт.
21
87700815
MULTIPOLE CONNECTOR,Male, 35 Pole
Product Bulkhead, CM5M
1шт.
87271930
NUT
Product Bulkhead, CM5M
1шт.
225039C1
TERMINAL
Product Bulkhead, CM5M
16шт.
87695915
ELEC. TERMINAL PIN,Male, Nickel, 1 - 2 mm
Product Bulkhead, CM5M
1шт.
223951A1
PIN
Product Bulkhead, CM5M
4шт.
22
87695723
ELEC CONNECTOR,Male , 3 Pole
Trans. Interface, C079M
1шт.
87695652
PLUG,12 - 16 Ga, White
Wedge, Trans. Interface, C079M
1шт.
225365C1
SOCKET
Trans. Interface, C079M
2шт.
86500035
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
Trans. Interface, C097M
2шт.
24
BN16174
DIODE,600V, 3A
3A, 600V
1шт.
25
87707115
CONTACT HOUSING,Female, 70 Pole
Cab Interface, C080F
1шт.
87695915
ELEC. TERMINAL PIN,Male, Nickel, 1 - 2 mm
Cab Interface, C080F
30шт.
225365C1
SOCKET
Cab Interface, C080F
4шт.
Выбрано товаров: 67
